Form 24.1 Survey

OMB #: 0925-0593

OMB Expiration Date: 8/31/2014

Child Blood Pressure Instrument, Phase 2g

OMB Specification

Child Blood Pressure Instrument

Event Category:	Time-Based
Event:	12M, 24M, 36M, 48M, 60M
Administration:	N/A
Instrument Target:	Child
Instrument Respondent:	Primary Caregiver
Domain:	Physical Measures
Document Category:	Physical Measures
Method:	Data Collector Administered
Mode (for this instrument*):	In-Person, CAI
OMB Approved Modes:	In-Person, CAI
Estimated Administration Time:	10 minutes
Multiple Child/Sibling Consideration:	Per Child
Special Considerations:	N/A
Version:	3.0
MDES Release:	4.0

*This instrument is OMB-approved for multi-mode administration but this version of the instrument is designed for administration in this/these mode(s) only.

This page intentionally left blank.

Child Blood Pressure Instrument

TABLE OF CONTENTS

GENERAL PROGRAMMER INSTRUCTIONS: 1

CHILD BLOOD PRESSURE INSTRUMENT 3

APPENDICES

APPENDIX A: REFERRAL TABLE 17

Appendix B: REFERRAL LEVELS BASED ON AGE AND PERCENTILE LENGTH/HEIGHT, BOYS 1-6 YEARS 18

APPENDIX C-1: MALE RECUMBENT LENGTH (AGE 11.0-24) PERCENTILES 25

APPENDIX C-2: MALE STANDING HEIGHT (AGE 24M+) PERCENTILES 26

Appendix D: BLOOD PRESSURE REFERRAL LEVELS BASED ON AGE AND PERCENTILE LENGTH/HEIGHT, GIRLS 1-6 YEARS. 28

APPENDIX E-1: FEMALE RECUMBENT LENGTH (AGE 11.0-24 M) PERCENTILES 35

APPENDIX E-2: FEMALE STANDING HEIGHT (AGE 24M +) PERCENTILES 36

This page intentionally left blank.

Child Blood Pressure Instrument

GENERAL PROGRAMMER INSTRUCTIONS:

WHEN PROGRAMMING INSTRUMENTS, VALIDATE FIELD LENGTHS AND TYPES AGAINST THE MDES TO ENSURE DATA COLLECTION RESPONSES DO NOT EXCEED THOSE OF THE MDES. SOME GENERAL ITEM LIMITS USED ARE AS FOLLOWS:

DATA ELEMENT FIELDS	MAXIMUM CHARACTERS PERMITTED	DATA TYPE	PROGRAMMER INSTRUCTIONS
ADDRESS AND EMAIL FIELDS	100	CHARACTER
UNIT AND PHONE FIELDS	10	CHARACTER
_OTH AND COMMENT FIELDS	255	CHARACTER	Limit text to 255 characters
FIRST NAME AND LAST NAME	30	CHARACTER	Limit text to 30 characters
ALL ID FIELDS	36	CHARACTER
ZIP CODE	5	NUMERIC
ZIP CODE LAST FOUR	4	NUMERIC
CITY	50	CHARACTER
DOB AND ALL OTHER DATE FIELDS (E.G., DT, DATE, ETC.)	10	NUMERIC CHARACTER	DISPLAY AS MM/DD/YYYY STORE AS YYYY-MM-DD HARD EDITS: MM MUST EQUAL 01 TO 12 DD MUST EQUAL 01 TO 31 YYYY MUST BE BETWEEN 1900 AND CURRENT YEAR.
TIME VARIABLES	TWO-DIGIT HOUR AND TWO-DIGIT MINUTE, AM/PM DESIGNATION	NUMERIC	HARD EDITS: HOURS MUST BE BETWEEN 00 AND 12; MINUTES MUST BE BETWEEN 00 AND 59

Instrument Guidelines for Participant and Respondent IDs:

PRENATALLY, THE P_ID IN THE MDES HEADER IS THAT OF THE PARTICIPANT (E.G. THE NON-PREGNANT WOMAN, PREGNANT WOMAN, OR THE FATHER).

POSTNATALLY, A RESPONDENT ID WILL BE USED IN ADDITION TO THE PARTICIPANT ID BECAUSE SOMEBODY OTHER THAN THE PARTICIPANT MAY BE COMPLETING THE INTERVIEW. FOR EXAMPLE, THE PARTICIPANT MAY BE THE CHILD AND THE RESPONDENT MAY BE THE MOTHER, FATHER, OR ANOTHER CAREGIVER. THEREFORE, MDES VERSION 2.2 AND ALL FUTURE VERSIONS CONTAIN A R_P_ID (RESPONDENT PARTICIPANT ID) HEADER FIELD FOR EACH POST-BIRTH INSTRUMENT. THIS WILL ALLOW ROCs TO INDICATE WHETHER THE RESPONDENT IS SOMEBODY OTHER THAN THE PARTICIPANT ABOUT WHOM THE QUESTIONS ARE BEING ASKED.

A REMINDER:

ALL RESPONDENTS MUST BE CONSENTED AND HAVE RECORDS IN THE PERSON, PARTICIPANT, PARTICIPANT_CONSENT AND LINK_PERSON_PARTICIPANT TABLES, WHICH CAN BE PRELOADED INTO EACH INSTRUMENT. ADDITIONALLY, IN POST-BIRTH QUESTIONNAIRES WHERE THERE IS THE ABILITY TO LOOP THROUGH A SET OF QUESTIONS FOR MULTIPLE CHILDREN, IT IS IMPORTANT TO CAPTURE AND STORE THE CORRECT CHILD P_ID ALONG WITH THE LOOP INFORMATION. IN THE MDES VARIABLE LABEL/DEFINITION COLUMN, THIS IS INDICATED AS FOLLOWS: EXTERNAL IDENTIFIER: PARTICIPANT ID FOR CHILD DETAIL.

CHILD BLOOD PRESSURE INSTRUMENT

(TIME_STAMP_CBP_ST).

PROGRAMMER INSTRUCTIONS

• INSERT DATE/TIME STAMP

• IF C_FNAME COLLECTED DURING PVST INSTRUMENT AND RESPONSE ≠ -1, -2 OR -4, PRELOAD C_FNAME.

• OTHERWISE, IF C_FNAME NOT COLLECTED DURING PVST INSTRUMENT OR RESPONSE = -1, -2 OR -4, DISPLAY “the child”.

• PRELOAD CHILD_DOB AND CHILD_SEX FROM PVST INSTRUMENT.

• PRELOAD (AN_CONV_WEIGHT_LBS)/(AN_CONV_WEIGHT_OZ) AND AN_CONV_RECUMBENT_LENGTH FROM ANTHROPOMETRY INSTRUMENT.

CBP01000/(BP_INTRO).

DATA COLLECTOR INSTRUCTIONS

• EXPLAIN THE BLOOD PRESSURE PROTOCOL TO THE PARENT OR CAREGIVER.

• IF THE PARENT OR CAREGIVER REFUSED THE BLOOD PRESSURE MEASUREMENTS, SELECT REFUSED.

• OTHERWISE, SELECT CONTINUE.

Label	Code	Go To
CONTINUE	1	BP_EQUIP_ID
REFUSED	-1

CBP02000/(BP_REF_REASON). I am sorry that you have chosen not to participate in this activity.  Can you please tell me why?

DATA COLLECTOR INSTRUCTIONS

• SELECT ALL THAT APPLY.

Label	Code	Go To
CONCERN ABOUT DISCOMFORT	1
CHILD SICK	2
CHILD TIRED/UNHAPPY	3
OTHER	-5
NONE GIVEN	-7

SOURCE

National Children’s Study, Vanguard Phase (Child BP)

PROGRAMMER INSTRUCTIONS

• IF BP_REF_REASON = ANY COMBINATION OF RESPONSE CODES 1 - 3, GO TO CBP06000.

• IF BP_REF_REASON = -5, OR ANY COMBINATION OF RESPONSE CODES 1 -3 AND -5, GO TO BP_REF_REASON_OTH.

• OTHERWISE, IF BP_REF_REASON = -7, DO NOT ALLOW SELECTION OF ADDITIONAL RESPONSE CODES AND GO TO CBP06000.

CBP03000/(BP_REF_REASON_OTH). SPECIFY: ________________________________

Label	Code	Go To
REFUSED	-1
DON'T KNOW	-2

SOURCE

National Children’s Study, Vanguard Phase (Child BP)

CBP06000. That’s fine.  Thank you for your time.

PROGRAMMER INSTRUCTIONS

GO TO TIME_STAMP_CBP_ET.

CBP07000/(BP_EQUIP_ID). RECORD EQUIPMENT ID.



|___|___|___| |___|___|___|___|___|___|___| |___|___|

DATA COLLECTOR INSTRUCTIONS

• SCAN BP MONITOR BARCODE.

• IF THE BARCODE SCANNER IS NOT WORKING, MANUALLY ENTER THE SERIAL NUMBER.



PROGRAMMER INSTRUCTIONS

• FORMAT BP_EQUIP_ID AS ONE OF THE FOLLOWING:

• SDT # # # # # # # # SP.

• SH6 # # # # # # # # SA

CBP08000/(BP_ARM_USED). RECORD ARM USED TO MEASURE BLOOD PRESSURE.

Label	Code	Go To
RIGHT	1
LEFT	2
REFUSED	-1
COULD NOT OBTAIN	-8

SOURCE



PROGRAMMER INSTRUCTIONS

• IF BP_ARM_USED = -1 OR -8, GO TO BP_MEAS_CNO_REASON.

• IF AN_MID_UPPER_ARM_CIRC_MEAN CALCULATED PREVIOUSLY, PRELOAD AN_MID_UPPER_ARM_CIRC_MEAN FROM ANTHROPOMETRY INSTRUMENT AND GO TO ?CBP11000.

• OTHERWISE, IF AN_MID_UPPER_ARM_CIRC_MEAN NOT CALCULATED PREVIOUSLY, GO TO BP_UPPER_ARM_LENGTH.

CBP09000/(BP_UPPER_ARM_LENGTH). UPPER ARM (HUMERUS) LENGTH.



|___|___|. |___| CM

DATA COLLECTOR INSTRUCTIONS

• IF UPPER ARM CIRCUMFERENCE NOT AVAILABLE FROM ANTHROPOMETRY EXAM, OBTAIN UPPER ARM (HUMERUS) LENGTH NOW.

Label	Code	Go To
REFUSED	-1	BP_MEAS_CNO_REASON
COULD NOT OBTAIN	-8	BP_MEAS_CNO_REASON

PROGRAMMER INSTRUCTIONS

• REFER TO APPENDIX A  (ANTHROPOMETRY EDIT RANGES) IN CHILD ANTHROPOMETRY INSTRUMENT:

• IF MEASUREMENT IS < 0 OR > 80 CM, DISPLAY HARD EDIT.

• IF MEASUREMENT FALLS OUTSIDE SOFT EDIT RANGE BASED ON AGE AND GENDER, WHERE CHILD AGE IS CALCULATED USING CHILD_DOB AND VISIT_DATE, DISPLAY SOFT EDIT.

• CREATE DERIVED VARIABLE, BP_MID_UPPER_ARM_LENGTH_MID WHERE BP_MID_UPPER_ARM_LENGTH_MID = BP_UPPER_ARM_LENGTH/2.

CBP10000/(BP_MID_UPPER_ARM_CIRC). UPPER ARM CIRCUMFERENCE, MEASURED AT {BP_MID_UPPER_ARM_LENGTH_MID}.



|___|___|. |___| CM

DATA COLLECTOR INSTRUCTIONS

• TAKE MID UPPER ARM CIRCUMFERENCE AT THE UPPER ARM (HUMERUS) MIDPOINT.

Label	Code	Go To
REFUSED	-1	BP_MEAS_CNO_REASON
COULD NOT OBTAIN	-8	BP_MEAS_CNO_REASON

PROGRAMMER INSTRUCTIONS

• DISPLAY BP_MID_UPPER_ARM_LENGTH_MID.

• REFER TO APPENDIX A (ANTHROPOMETRY EDIT RANGES) IN CHILD ANTHROPOMETRY INSTRUMENT:

• IF MEASUREMENT IS < 0 OR > 80 CM, DISPLAY HARD EDIT.

• IF MEASUREMENT FALLS OUTSIDE SOFT EDIT RANGE BASED ON AGE AND GENDER, WHERE CHILD AGE IS CALCULATED USING CHILD_DOB AND VISIT_DATE, DISPLAY SOFT EDIT.



CBP11000. RECOMMENDED CUFF SIZE: {CUFF SIZE}

PROGRAMMER INSTRUCTIONS

• DISPLAY THE APPROPRIATE CUFF SIZE FOR {CUFF SIZE} AS FOLLOWS:

• IF BP_MID_UPPER_ARM_CIRC  < 8 CM OR > 50 CM, DISPLAY “COULD NOT OBTAIN."

• IF BP_MID_UPPER_ARM_CIRC > 8 CM AND < 11.9 CM, DISPLAY ”INFANT”.

• IF BP_MID_UPPER_ARM_CIRC > 12 CM AND < 16.9 CM, DISPLAY ”CHILD”.

• IF BP_MID_UPPER_ARM_CIRC > 17 CM AND < 21.9 CM, DISPLAY ”SMALL ADULT”.

• IF BP_MID_UPPER_ARM_CIRC > 22 CM AND < 29.9 CM, DISPLAY “ADULT”.

• IF BP_MID_UPPER_ARM_CIRC > 30 CM AND < 37.9 CM, DISPLAY “LARGE ADULT”.

• IF BP_MID_UPPER_ARM_CIRC > 38 CM AND < 50 CM, DISPLAY “THIGH”.

CBP12000/(BP_CUFF_SIZE_USED). SELECT BLOOD PRESSURE CUFF SIZE USED FOR MEASUREMENTS.

Label	Code	Go To
INFANT	1
CHILD	2
SMALL ADULT	3
ADULT	4
LARGE ADULT	5
THIGH	6

DATA COLLECTOR INSTRUCTIONS

• RECORD CUFF SIZE USED.

CBP13000. BLOOD PRESSURE 1 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• OBTAIN FIRST SET OF BLOOD PRESSURE MEASUREMENTS.

(BP_SYS_MEAS1) SYSTOLIC:     |___|___|___| mmHg

Label	Code	Go To
REFUSED	-1	BP_MEAS_CNO_REASON
COULD NOT OBTAIN	-8	BP_MEAS_CNO_REASON

(BP_DIA_MEAS1) DIASTOLIC:   |___|___|___| mmHg

(BP_PULSE_MEAS1) PULSE:           |___|___|___| BPM

PROGRAMMER INSTRUCTIONS

• IF DIFFERENCE BETWEEN BP_SYS_MEAS1 AND BP_DIA_MEAS1 < 20 MMHG, DISPLAY MESSAGE “THE DIFFERENCE BETWEEN THE SYSTOLIC BP AND DIASTOLIC BP IS LESS THAN 20 MMHG. ARE YOU SURE?” REQUIRE SELECTION OF “YES” OR “NO” TO THIS QUESTION.

• IF “YES” SELECTED, ACCEPT THE VALUE AND GO TO NEXT FIELD.

• IF “NO” SELECTED, DISPLAY MESSAGE “PLEASE ENTER A CORRECTED VALUE FOR SYSTOLIC BP AND/OR DIASTOLIC BP.” ALLOW ENTRY IN BP_SYS_MEAS1 AND BP_DIA_MEAS1.

• IF DIFFERENCE BETWEEN BP_SYS_MEAS1 AND BP_DIA_MEAS1 > 100, DISPLAY MESSAGE “THE DIFFERENCE BETWEEN THE SYSTOLIC BP AND DIASTOLIC BP IS GREATER THAN 100 MMHG. ARE YOU SURE?” REQUIRE SELECTION OF “YES” OR “NO” TO THIS QUESTION.

• IF “YES” IS SELECTED, ACCEPT THE VALUE AND GO TO BP_POSITION_MEAS1.

• IF “NO” SELECTED, DISPLAY MESSAGE “PLEASE ENTER A CORRECTED VALUE FOR SYSTOLIC BP AND/OR DIASTOLIC BP.” ALLOW ENTRY IN BP_SYS_MEAS1 AND BP_DIA_MEAS1.

• IF BP_SYS_MEAS1 AND/OR BP_DIA_MEAS1 > 290:

• DO NOT ACCEPT THIS VALUE.

• DISPLAY MESSAGE “THIS VALUE IS NOT WITHIN ACCEPTABLE LIMITS. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE (<290).” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW ENTRY IN BP_SYS_MEAS1 AND BP_DIA_MEAS1.

• IF BP_DIA_MEAS1 > BP_SYS_MEAS1, DISPLAY MESSAGE “DIASTOLIC BP MUST BE LESS THAN SYSTOLIC BP. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ. ALLOW NEW ENTRY IN BP_SYS_MEAS1 AND BP_DIA_MEAS1.

• IF BP_SYS_MEAS1 = -1 OR -8:

• DO NOT ACCEPT A VALUE FOR DIASTOLIC BP OR PULSE

• DISPLAY MESSAGE “PLEASE ENTER A VALUE FOR SYSTOLIC BP.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW NEW ENTRY IN BP_SYS_MEAS1.

• IF BP_SYS_MEAS1 = 0:

• DO NOT ACCEPT THIS VALUE.

• DISPLAY MESSAGE “SYSTOLIC BP CANNOT EQUAL ZERO. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE OR SELECT COULD NOT OBTAIN.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW NEW ENTRY IN BP_SYS_MEAS1.

CBP14000/(BP_POSITION_MEAS1). ​CHILD’S POSITION FOR BLOOD PRESSURE 1 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• SELECT POSITION OF CHILD FOR FIRST SET OF BLOOD PRESSURE MEASUREMENTS.

Label	Code	Go To
SEATED	1
SUPINE	2
UPRIGHT	3

CBP15000/(BP_STATE_MEAS1). CHILD’S STATE FOR BLOOD PRESSURE 1 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• SELECT STATE OF CHILD FOR FIRST SET OF BLOOD PRESSURE MEASUREMENTS.

Label	Code	Go To
AWAKE	1
SLEEPING	2
CRYING	3

CBP16000/(BP_MEAS1_COM).

DATA COLLECTOR INSTRUCTIONS

• ENTER COMMENTS ABOUT THE FIRST SET OF BLOOD PRESSURE MEASUREMENTS, THE CHILD’S POSITION, AND THE CHILD’S STATE.

• SELECT ALL THAT APPLY.

Label	Code	Go To
NONE	1
CHILD DID NOT REST FOR FIVE MINUTES	2
LEGS WERE CROSSED	3
OTHER	-5

PROGRAMMER INSTRUCTIONS

• IF BP_MEAS1_COM = 1, DO NOT ALLOW SELECTION OF ADDITIONAL RESPONSES AND GO TO CBP18000.

• IF BP_MEAS1_COM = 2 AND/OR 3, GO TO CBP18000.

• IF BP_MEAS1_COM = -5 OR 2 AND/OR 3 AND -5, GO TO BP_MEAS1_COM_OTH.

CBP17000/(BP_MEAS1_COM_OTH). SPECIFY: __________________________

CBP18000. BLOOD PRESSURE 2 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• OBTAIN SECOND SET OF BLOOD PRESSURE MEASUREMENTS.

(BP_SYS_MEAS2) SYSTOLIC:     |___|___|___| mmHg

Label	Code	Go To
REFUSED	-1	BP_MEAS_CNO_REASON
COULD NOT OBTAIN	-8	BP_MEAS_CNO_REASON

(BP_DIA_MEAS2) DIASTOLIC:   |___|___|___| mmHg

(BP_PULSE_MEAS2) PULSE:           |___|___|___| BPM

PROGRAMMER INSTRUCTIONS

• IF DIFFERENCE BETWEEN BP_SYS_MEAS2 AND BP_DIA_MEAS2 < 20 MMHG, DISPLAY MESSAGE “THE DIFFERENCE BETWEEN THE SYSTOLIC BP AND DIASTOLIC BP IS LESS THAN 20 MMHG. ARE YOU SURE?” REQUIRE SELECTION OF “YES” OR “NO” TO THIS QUESTION.

• IF “YES” SELECTED, ACCEPT THE VALUE AND GO TO BP_POSITION_MEAS2.

• IF “NO” SELECTED, DISPLAY MESSAGE “PLEASE ENTER A CORRECTED VALUE FOR SYSTOLIC BP AND/OR DIASTOLIC BP.” ALLOW ENTRY IN BP_SYS_MEAS2 AND BP_DIA_MEAS2.

• IF DIFFERENCE BETWEEN BP_SYS_MEAS2 AND BP_DIA_MEAS2 > 100, DISPLAY MESSAGE “THE DIFFERENCE BETWEEN THE SYSTOLIC BP AND DIASTOLIC BP IS GREATER THAN 100 MMHG. ARE YOU SURE?” REQUIRE SELECTION OF “YES” OR “NO” TO THIS QUESTION.

• IF “YES” IS SELECTED, ACCEPT THE VALUE AND GO TO BP_POSITION_MEAS2.

• IF “NO” SELECTED, DISPLAY MESSAGE “PLEASE ENTER A CORRECTED VALUE FOR SYSTOLIC BP AND/OR DIASTOLIC BP.” ALLOW ENTRY IN BP_SYS_MEAS2 AND BP_DIA_MEAS2.

• IF BP_SYS_MEAS2 AND/OR BP_DIA_MEAS2 > 290:

• DO NOT ACCEPT THIS VALUE.

• DISPLAY MESSAGE “THIS VALUE IS NOT WITHIN ACCEPTABLE LIMITS. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE (<290).” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW ENTRY IN BP_SYS_MEAS2 AND/OR BP_DIA_MEAS2.

• IF BP_DIA_MEAS2 > BP_SYS_MEAS2:

• DISPLAY MESSAGE “DIASTOLIC BP MUST BE LESS THAN SYSTOLIC BP. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW NEW ENTRY IN BP_SYS_MEAS2 AND/OR BP_DIA_MEAS2.

• IF BP_SYS_MEAS2 = -1 OR -8:

• DO NOT ACCEPT A VALUE FOR DIASTOLIC BP OR PULSE

• DISPLAY MESSAGE “PLEASE ENTER A VALUE FOR SYSTOLIC BP.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW NEW ENTRY IN BP_SYS_MEAS2.

• IF BP_SYS_MEAS2 = 0:

• DO NOT ACCEPT THIS VALUE.

• DISPLAY MESSAGE “SYSTOLIC BP CANNOT EQUAL ZERO. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE OR SELECT COULD NOT OBTAIN.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW NEW ENTRY IN BP_SYS_MEAS2.

CBP19000/(BP_POSITION_MEAS2). CHILD’S POSITION FOR BLOOD PRESSURE 2 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• SELECT POSITION OF CHILD FOR SECOND SET OF BLOOD PRESSURE MEASUREMENTS.

Label	Code	Go To
SEATED	1
SUPINE	2
UPRIGHT	3

CBP20000/(BP_STATE_MEAS2). CHILD’S STATE FOR BLOOD PRESSURE 2 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• SELECT STATE OF CHILD FOR SECOND SET OF BLOOD PRESSURE MEASUREMENTS.

Label	Code	Go To
AWAKE	1
SLEEPING	2
CRYING	3

CBP21000/(BP_MEAS2_COM).

DATA COLLECTOR INSTRUCTIONS

• ENTER COMMENTS ABOUT THE SECOND SET OF BLOOD PRESSURE MEASUREMENTS, THE CHILD’S POSITION, AND THE CHILD’S STATE.

• SELECT ALL THAT APPLY.

Label	Code	Go To
NONE	1
CHILD DID NOT REST FOR 30 SECONDS	2
LEGS WERE CROSSED	3
OTHER	-5

PROGRAMMER INSTRUCTIONS

• IF BP_MEAS2_COM = 1, DO NOT ALLOW SELECTION OF ADDITIONAL RESPONSES AND GO TO CBP23000.

• IF BP_MEAS2_COM = 2 AND/OR 3, GO TO CBP23000.

• IF BP_MEAS2_COM = -5 OR 2 AND/OR 3 AND -5, GO TO BP_MEAS2_COM_OTH.

CBP22000/(BP_MEAS2_COM_OTH). SPECIFY: __________________________

CBP23000. BLOOD PRESSURE 3 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• OBTAIN THIRD SET OF BLOOD PRESSURE MEASUREMENTS.

(BP_SYS_MEAS3) SYSTOLIC:     |___|___|___| mmHg

Label	Code	Go To
REFUSED	-1	BP_MEAS_CNO_REASON
COULD NOT OBTAIN	-8	BP_MEAS_CNO_REASON

(BP_DIA_MEAS3) DIASTOLIC:   |___|___|___| mmHg

(BP_PULSE_MEAS3) PULSE:           |___|___|___| BPM

PROGRAMMER INSTRUCTIONS

• IF DIFFERENCE BETWEEN BP_SYS_MEAS3 AND BP_DIA_MEAS3 < 20 MMHG, DISPLAY MESSAGE “THE DIFFERENCE BETWEEN THE SYSTOLIC BP AND DIASTOLIC BP IS LESS THAN 20 MMHG. ARE YOU SURE?” REQUIRE SELECTION OF “YES” OR “NO” TO THIS QUESTION.

• IF “YES” SELECTED, ACCEPT THE VALUE AND GO TO BP_POSTION_MEAS3.

• IF “NO” SELECTED, DISPLAY MESSAGE “PLEASE ENTER A CORRECTED VALUE FOR SYSTOLIC BP AND/OR DIASTOLIC BP.” ALLOW ENTRY IN BP_SYS_MEAS3 AND BP_DIA_MEAS3.

• IF DIFFERENCE BETWEEN BP_SYS_MEAS3 AND BP_DIA_MEAS3 > 100, DISPLAY MESSAGE “THE DIFFERENCE BETWEEN THE SYSTOLIC BP AND DIASTOLIC BP IS GREATER THAN 100 MMHG. ARE YOU SURE?” REQUIRE SELECTION OF “YES” OR “NO” TO THIS QUESTION.

• IF “YES” IS SELECTED, ACCEPT THE VALUE AND GO TO BP_POSITION_MEAS1.

• IF “NO” SELECTED, DISPLAY MESSAGE “PLEASE ENTER A CORRECTED VALUE FOR SYSTOLIC BP AND/OR DIASTOLIC BP.” ALLOW ENTRY IN BP_SYS_MEAS3 AND BP_DIA_MEAS3.

• IF BP_SYS_MEAS3 AND/OR BP_DIA_MEAS3 > 290:

• DO NOT ACCEPT THIS VALUE.

• DISPLAY MESSAGE “THIS VALUE IS NOT WITHIN ACCEPTABLE LIMITS. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE (<290).” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW ENTRY IN BP_SYS_MEAS3 AND BP_DIA_MEAS3.

• IF BP_DIA_MEAS3 > BP_SYS_MEAS3, DISPLAY MESSAGE “DIASTOLIC BP MUST BE LESS THAN SYSTOLIC BP. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ. ALLOW NEW ENTRY IN BP_SYS_MEAS3 AND BP_DIA_MEAS3.

• IF BP_SYS_MEAS3 = -1 OR -8:

• DO NOT ACCEPT A VALUE FOR DIASTOLIC BP OR PULSE

• DISPLAY MESSAGE “PLEASE ENTER A VALUE FOR SYSTOLIC BP.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW NEW ENTRY IN BP_SYS_MEAS3.

• IF BP_SYS_MEAS3 = 0:

• DO NOT ACCEPT THIS VALUE.

• DISPLAY MESSAGE “SYSTOLIC BP CANNOT EQUAL ZERO. PLEASE ENTER A VALUE WITHIN THE ACCEPTABLE RANGE OR SELECT COULD NOT OBTAIN.” REQUIRE SELECTION OF “OK” TO CONFIRM MESSAGE WAS READ.

• ALLOW NEW ENTRY IN BP_SYS_MEAS3.

CBP24000/(BP_POSITION_MEAS3). CHILD’S POSITION FOR BLOOD PRESSURE 3 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• SELECT POSITION OF CHILD FOR THIRD SET OF BLOOD PRESSURE MEASUREMENTS.

Label	Code	Go To
SEATED	1
SUPINE	2
UPRIGHT	3

CBP25000/(BP_STATE_MEAS3). CHILD’S STATE FOR BLOOD PRESSURE 3 MEASUREMENTS.

DATA COLLECTOR INSTRUCTIONS

• SELECT STATE OF CHILD FOR THIRD SET OF BLOOD PRESSURE MEASUREMENTS.

Label	Code	Go To
AWAKE	1
SLEEPING	2
CRYING	3

CBP26000/(BP_MEAS3_COM).

DATA COLLECTOR INSTRUCTIONS

• ENTER COMMENTS ABOUT THE THIRD SET OF BLOOD PRESSURE MEASUREMENTS, THE CHILD’S POSITION, AND THE CHILD’S STATE.

• SELECT ALL THAT APPLY.

Label	Code	Go To
NONE	1
CHILD DID NOT REST FOR 30 SECONDS	2
LEGS WERE CROSSED	3
OTHER	-5

PROGRAMMER INSTRUCTIONS

• IF BP_MEAS3_COM = 1, DO NOT ALLOW SELECTION OF ADDITIONAL RESPONSES AND GO TO BP_MEAS_COM.

• IF BP_MEAS3_COM = 2 AND/OR 3, GO TO BP_MEAS_COM.

• IF BP_MEAS3_COM = -5 OR 2 AND/OR 3, AND -5, GO TO BP_MEAS3_COM _OTH.

CBP27000/(BP_MEAS3_COM _OTH). SPECIFY: __________________________

PROGRAMMER INSTRUCTIONS

• GO TO BP_MEAS_COM.

CBP28000/(BP_MEAS_CNO_REASON).

DATA COLLECTOR INSTRUCTIONS

• ENTER REASON(S) YOU COULD NOT OBTAIN ANY BLOOD PRESSURE MEASURE(S).

• SELECT ALL THAT APPLY.

Label	Code	Go To
PARENT/CAREGIVER REFUSAL	1
CHILD REFUSAL	2
COMMUNICATION ISSUES	3
PARENT/CAREGIVER ILL/EMERGENCY	4
CHILD ILL/EMERGENCY	5
NO TIME	6
EQUIPMENT FAILURE	7
SAFETY EXCLUSION	8
PHYSICAL LIMITATION	9
DATA COLLECTOR ERROR	10
OTHER	-5
NONE GIVEN	-7

PROGRAMMER INSTRUCTIONS

• IF BP_MEAS_CNO_REASON = -5 OR ANY COMBINATION OF RESPONSES 1 - 10 AND -5, GO TO BP_MEAS_CNO_REASON_OTH.

• IF BP_MEAS_CNO_REASON = -7, DO NOT ALLOW SELECTION OF ADDITIONAL RESPONSES AND GO TO BP_MEAS_COM.

• IF BP_MEAS_CNO_REASON = ANY COMBINATION OF 1 - 10, GO TO BP_MEAS_COM.

CBP29000/(BP_MEAS_CNO_REASON_OTH). SPECIFY: ________________________________________

CBP30000/(BP_MEAS_COM).

DATA COLLECTOR INSTRUCTIONS

• ENTER COMMENTS OVERALL ABOUT THE BLOOD PRESSURE MEASUREMENTS, THE CHILD’S POSITION, AND THE CHILD’S STATE.

• SELECT ALL THAT APPLY.

Label	Code	Go To
NONE	1
CHILD DID NOT REST FOR FIVE MINUTES	2
CHILD DID NOT REST FOR 30 SECONDS	3
LEGS WERE CROSSED	4
OTHER	-5

PROGRAMMER INSTRUCTIONS

• IF BP_MEAS_COM = 1, DO NOT ALLOW SELECTION OF ADDITIONAL RESPONSES AND GO TO CBP32000.

• IF BP_MEAS_COM = ANY COMBINATION OF 2 - 4, GO TO CBP32000.

• IF BP_MEAS_COM = -5 OR ANY COMBINATION OF 2 - 4 AND -5, GO TO BP_MEAS_COM_OTH.

CBP31000/(BP_MEAS_COM_OTH). SPECIFY: __________________________

CBP32000. AVERAGE SYSTOLIC BLOOD PRESSURE: {BP_SYS_AVG}

DIASTOLIC BLOOD PRESSURE: {BP_DIA_AVG}

PULSE: {BP_PULSE_AVG}

DATA COLLECTOR INSTRUCTIONS

• RECORD VALUES DISPLAYED FOR SYSTOLIC BLOOD PRESSURE IN “MMHG”, DIASTOLIC BLOOD PRESSURE IN “MMHG”, AND PULSE IN “BEATS PER MINUTE” ON REPORT OF FINDINGS FORM.

• IF “COULD NOT BE OBTAINED” IS DISPLAYED, CHECK BOX FOR "COULD NOT OBTAIN" FOR BLOOD PRESSURE AND HEART RATE.

PROGRAMMER INSTRUCTIONS

• CREATE AND SAVE DERIVED VARIABLE, BP_SYS_AVG, FOR SYSTOLIC BLOOD PRESSURE AVERAGE.  CALCULATE BP_SYS_AVG AS FOLLOWS:

• IF 3 VALUES COLLECTED FOR BP_SYS_MEAS1, BP_SYS_MEAS2,  AND BP_SYS_MEAS3:

• IGNORE BP_SYS_MEAS1.

• CALCULATE THE AVERAGE FOR BP_SYS_MEAS2 AND BP_SYS_MEAS3.

• IF 2 VALUES COLLECTED FOR BP_SYS_MEAS1 AND BP_SYS_MEAS2, USE BP_SYS_MEAS2 AS BP_SYS_AVG.

• IF 1 VALUE COLLECTED FOR BP_SYS_MEAS1, USE BP_SYS_MEAS1 AS BP_SYS_AVG.

• IF BP_SYS_MEAS1 = -1 OR -8, SET BP_SYS_AVG TO "COULD NOT OBTAIN".

• CREATE AND SAVE DERIVED VARIABLE, BP_DIA_AVG, FOR DIASTOLIC BLOOD PRESSURE AVERAGE. CALCULATE BP_DIA_AVG AS FOLLOWS:

• IF 3 VALUES COLLECTED FOR BP_DIA_MEAS1, BP_DIA_MEAS2, AND BP_DIA_MEAS3:

• IGNORE BP_DIA_MEAS1.

• CALCULATE THE AVERAGE FOR BP_DIA_MEAS2 AND BP_DIA_MEAS3.

• IF 2 VALUES COLLECTED FOR BP_DIA_MEAS1 AND BP_DIA_MEAS2, USE BP_DIA_MEAS2 AS BP_DIA_AVG.

• IF 1 VALUE COLLECTED FOR BP_SYS_MEAS1, USE BP_DIA_MEAS1 AS BP_DIA_AVG.

• IF BP_SYS_MEAS1 = -1 OR -8, SET BP_DIA_AVG TO "COULD NOT OBTAIN".

• CREATE AND SAVE DERIVED VARIABLE, BP_PULSE_AVG, FOR PULSE AVERAGE. CALCULATE BP_PULSE_AVG AS FOLLOWS:

• IF 3 VALUES COLLECTED FOR BP_PULSE_MEAS1, BP_PULSE_MEAS2, AND BP_PULSE_MEAS3:

• IGNORE BP_PULSE_MEAS1.

• CALCULATE THE AVERAGE FOR BP_PULSE_MEAS2 AND BP_PULSE_MEAS3.

• IF 2 VALUES COLLECTED FOR BP_PULSE_MEAS1 AND BP_PULSE_MEAS2, USE BP_PULSE_MEAS2 AS BP_PULSE_AVG.

• IF 1 VALUE COLLECTED FOR BP_PULSE_MEAS1, USE BP_PULSE_MEAS1 AS BP_PULSE_AVG.

• IF BP_SYS_MEAS1 = -1 OR -8, SET BP_PULSE_AVG TO "COULD NOT OBTAIN".

• IF AVERAGES WERE CALCULATED, DISPLAY BP_SYS_AVG, BP_DIA_AVG, AND BP_PULSE_AVG.

• OTHERWISE, IF BP_SYS_MEAS1 = -1 OR -8, DISPLAY “COULD NOT BE OBTAINED”.

CBP33000. BLOOD PRESSURE REFERRAL LEVEL.

DATA COLLECTOR INSTRUCTIONS

• COMPLETE REPORT OF FINDINGS USING INFORMATION DISPLAYED AND THEN GIVE REPORT OF FINDINGS (AND REFERRAL LETTER IF APPLICABLE) TO PARENT OR CAREGIVER.

PROGRAMMER INSTRUCTIONS

• CREATE CATEGORY AND REFFERAL LEVEL BASED ON INSTRUCTIONS IN APPENDICES A THROUGH E:

• IF REFERRAL CATEGORY =1, DISPLAY, “IN THE REPORT OF FINDINGS, CHECK BOXES ‘IS WITHIN NORMAL RANGE’ AND ‘NO ACTION IS NEEDED.'  PLEASE NOTE THAT THERE IS NO REFERRAL LETTER.”

• IF REFERRAL CATEGORY = 2, DISPLAY, “IN THE REPORT OF FINDINGS, CHECK BOXES ‘NORMAL BUT AT THE HIGH END OF NORMAL’ AND ‘DISCUSS THESE FINDINGS WITH A HEALTH CARE PROVIDER AT NEXT VISIT.’  PLEASE NOTE THAT THERE IS NO REFERRAL LETTER.”

• IF REFERRAL CATEGORY = 3, DISPLAY, “IN THE REPORT OF FINDINGS, CHECK BOXES ‘HIGH’ AND ‘SEE A HEALTH CARE PROVIDER WITHIN 2 WEEKS.’ GIVE PARENT/CAREGIVER A REFERRAL LETTER.”

• IF REFERRAL CATEGORY = 4, DISPLAY, “IN THE REPORT OF FINDINGS, CHECK BOXES ‘VERY HIGH’ AND ‘SEE A HEALTH CARE PROVIDER IMMEDIATELY.’  GIVE PARENT/CAREGIVER A REFERRAL LETTER.”

• IF REFERRAL CATEGORY = N/A, DISPLAY “IN THE REPORT OF FINDINGS, CHECK 'N/A' BOX AND DO NOT CHECK A RECOMMENDED ACTION BOX.    PLEASE NOTE THAT THERE IS NO REFERRAL LETTER.”

CBP34000. {Thank you for taking the time to answer these questions./Thank you for having {C_FNAME/the child} complete these blood pressure measures.}

PROGRAMMER INSTRUCTIONS

• IF BP_ARM_USED = -1 OR -8 OR BP_UPPER_ARM_LENGTH = -1 OR -8 OR BP_MID_UPPER_ARM_CIRC = -1 OR -8 OR BP_CUFF_SIZE_USED = -8 OR (BP_SYS_MEAS1)(BP_DIA_MEAS1)(BP_PULSE_MEAS1) = -1 OR -8,  DISPLAY FIRST BRACKETED PHRASE.

• OTHERWISE, DISPLAY SECOND BRACKETED PHRASE.

(TIME_STAMP_CBP_ET).

PROGRAMMER INSTRUCTIONS

• INSERT DATE/TIME STAMP

APPENDIX A: REFERRAL TABLE

Category	Statement Displayed
N/A	IN THE REPORT OF FINDINGS, CHECK BOX “N/A” AND DO NOT CHECK A RECOMMENDED ACTION BOX. PLEASE NOTE THAT THERE IS NO REFERRAL LETTER.
Category 4	IN THE REPORT OF FINDINGS, CHECK BOX “VERY HIGH” AND “SEE A HEALTH CARE PROVIDER IMMEDIATELY.” GIVE PARENT/CAREGIVER A REFERRAL LETTER.
Category 3	IN THE REPORT OF FINDINGS, CHECK BOX “HIGH” AND “SEE A HEALTH CARE PROVIDER WITHIN 2 WEEKS.” GIVE PARENT/CAREGIVER A REFERRAL LETTER.
Category 2	IN THE REPORT OF FINDINGS, CHECK BOX “NORMAL BUT AT THE HIGH END OF NORMAL”AND “DISCUSS THESE FINDINGS WITH A HEALTH CARE PROVIDER AT NEXT VISIT.” PLEASE NOTE THAT THERE IS NO REFERRAL LETTER.
Category 1	IN THE REPORT OF FINDINGS, CHECK BOX “IS WITHIN NORMAL RANGE” AND “NO ACTION IS NEEDED.” PLEASE NOTE THAT THERE IS NO REFERRAL LETTER.

Appendix B: REFERRAL LEVELS BASED ON AGE AND PERCENTILE LENGTH/HEIGHT, BOYS 1-6 YEARS

Boys - Age 1 (11 Months +)

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<49	49-53	54-66	 67
< 94	1	2	3	4
94-97	2	2	3	4
98-110	3	3	3	4
 111	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<50	50-53	54-67	 68
< 95	1	2	3	4
95-98	2	2	3	4
99-111	3	3	3	4
 112	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<51	51-54	55-68	 69
< 97	1	2	3	4
97-100	2	2	3	4
101-113	3	3	3	4
 114	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<52	52-55	56-69	 70
<99	1	2	3	4
99-102	2	2	3	4
103-115	3	3	3	4
 116	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<53	53-56	57-70	 71
< 100	1	2	3	4
100-103	2	2	3	4
104-117	3	3	3	4
 118	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<53	53-57	58-71	 72
< 102	1	2	3	4
102-105	2	2	3	4
106-118	3	3	3	4
 119	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<54	54-57	58-71	 72
< 103	1	2	3	4
103-105	2	2	3	4
106-119	3	3	3	4
 120	4	4	4	4

Boys - Age 2

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<54	54-58	59-71	 72
< 97	1	2	3	4
97-100	2	2	3	4
101-114	3	3	3	4
 115	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<55	55-58	59-72	 73
< 99	1	2	3	4
99-101	2	2	3	4
102-115	3	3	3	4
 116	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<56	56- 59	60-73	 74
< 100	1	2	3	4
100-103	2	2	3	4
104-118	3	3	3	4
 119	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<57	57-60	61-74	 75
< 102	1	2	3	4
102-105	2	2	3	4
106-118	3	3	3	4
 119	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<58	58-61	62-75	 76
< 104	1	2	3	4
104-107	2	2	3	4
108-120	3	3	3	4
 121	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<58	58-62	63-76	 77
< 105	1	2	3	4
105-108	2	2	3	4
109-122	3	3	3	4
 123	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<59	59-62	63-76	 77
< 106	1	2	3	4
106-109	2	2	3	4
110-122	3	3	3	4
 123	4	4	4	4

Boys - Age 3

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<59	59-62	63-76	 77
< 100	1	2	3	4
100-103	2	2	3	4
104-116	3	3	3	4
 117	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<59	59-62	63-76	 77
< 101	1	2	3	4
101-104	2	2	3	4
105-117	3	3	3	4
 118	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<60	60-63	64-77	 78
< 103	1	2	3	4
103-106	2	2	3	4
107-119	3	3	3	4
 120	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<61	61-64	65-78	 79
< 105	1	2	3	4
105-108	2	2	3	4
109-121	3	3	3	4
 122	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<62	62-65	66-79	 80
< 107	1	2	3	4
107-109	2	2	3	4
110-123	3	3	3	4
 124	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<63	63-66	67-80	 81
< 108	1	2	3	4
108-111	2	2	3	4
112-124	3	3	3	4
 125	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<63	63-66	67-80	 81
< 109	1	2	3	4
109-112	2	2	3	4
113-125	3	3	3	4
 126	4	4	4	4

Boys - Age 4

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<62	62-65	66-73	 74
< 102	1	2	3	4
102-105	2	2	3	4
106-112	3	3	3	4
 113	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<63	63-66	67-74	 75
< 103	1	2	3	4
103-106	2	2	3	4
107-113	3	3	3	4
 114	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<64	64-67	68-75	 76
< 105	1	2	3	4
105-108	2	2	3	4
109-115	3	3	3	4
 116	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<65	65-68	69-76	 77
< 107	1	2	3	4
107-110	2	2	3	4
111-117	3	3	3	4
 118	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<66	66-69	70-77	 78
< 109	1	2	3	4
109-111	2	2	3	4
112-119	3	3	3	4
 120	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<66	66-70	71-77	 78
< 110	1	2	3	4
110-113	2	2	3	4
114-120	3	3	3	4
 121	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<67	67-70	71-78	 79
< 111	1	2	3	4
111-114	2	2	3	4
115-121	3	3	3	4
 122	4	4	4	4

Boys - Age 5

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<65	65-68	69-76	 77
< 104	1	2	3	4
104-107	2	2	3	4
108-114	3	3	3	4
 115	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<66	66-69	70-77	 78
< 105	1	2	3	4
105-108	2	2	3	4
109-115	3	3	3	4
 116	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<67	67-70	71-78	 79
< 106	1	2	3	4
106-109	2	2	3	4
110-117	3	3	3	4
 118	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<68	68-71	72-79	 80
< 108	1	2	3	4
108-111	2	2	3	4
112-119	3	3	3	4
 120	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<69	69-72	73-80	 81
< 110	1	2	3	4
110-113	2	2	3	4
114-120	3	3	3	4
 121	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<69	69-73	74-80	 81
< 111	1	2	3	4
111-114	2	2	3	4
115-122	3	3	3	4
 123	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<70	70-73	74-81	 82
< 112	1	2	3	4
112-115	2	2	3	4
116-122	3	3	3	4
 123	4	4	4	4

Boys - Age 6

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<68	68-71	72-85	 86
< 105	1	2	3	4
105-108	2	2	3	4
109-121	3	3	3	4
 122	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<68	68-71	72-85	 86
< 106	1	2	3	4
106-109	2	2	3	4
110-122	3	3	3	4
 123	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<69	69-72	73-86	 87
< 108	1	2	3	4
108-111	2	2	3	4
112-124	3	3	3	4
 125	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<70	70-73	74-87	 88
< 110	1	2	3	4
110-113	2	2	3	4
114-126	3	3	3	4
 127	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<71	71-74	75-88	 89
< 111	1	2	3	4
111-114	2	2	3	4
115-128	3	3	3	4
 129	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<72	72-75	76-90	 91
< 113	1	2	3	4
113-116	2	2	3	4
117-129	3	3	3	4
 130	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<72	72-75	76-89	 90
< 113	1	2	3	4
113-116	2	2	3	4
117-130	3	3	3	4
 131	4	4	4	4

APPENDIX C-1: MALE RECUMBENT LENGTH (AGE 11.0-24) PERCENTILES

Length (Age 11.0 m - 24 m) Percentiles
If age in months is greater than or =	and less than	P10 - P24	P25 - P49	P50 - P74	P75 - P89	P90 - P94	P95 - >
11	12	71.55	72.97	74.54	76.11	77.52	78.37
12	13	72.70	74.15	75.75	77.35	78.79	79.66
13	14	73.81	75.28	76.92	78.55	80.03	80.91
14	15	74.87	76.38	78.05	79.72	81.22	82.12
15	16	75.90	77.44	79.15	80.85	82.39	83.31
16	17	76.90	78.47	80.21	81.95	83.52	84.46
17	18	77.86	79.47	81.25	83.03	84.63	85.60
18	19	78.80	80.44	82.26	84.08	85.72	86.70
19	20	79.71	81.38	83.24	85.10	86.77	87.77
20	21	80.59	82.30	84.20	86.1	87.81	88.83
21	22	81.45	83.2	85.14	87.07	88.82	89.86
22	23	82.29	84.07	86.05	88.03	89.81	90.87
23	24	83.10	84.92	86.94	88.96	90.78	91.87
24	25	83.90	85.76	87.82	89.88	91.73	92.84

APPENDIX C-2: MALE STANDING HEIGHT (AGE 24M+) PERCENTILES

Height (Age 24 m +) Percentiles
If age in months is greater than or =	and less than	P10 - P24	P25 - P49	P50 - P74	P75 - P89	P90 - P94	P95 - >
24	25	82.36	84.49	86.86	89.23	91.36	92.63
25	26	83.11	85.26	87.65	90.06	92.23	93.53
26	27	83.85	86.01	88.42	90.86	93.08	94.41
27	28	84.57	86.74	89.18	91.65	93.90	95.26
28	29	85.27	87.45	89.91	92.41	94.70	96.08
29	30	85.96	88.15	90.63	93.16	95.48	96.88
30	31	86.64	88.84	91.33	93.88	96.23	97.66
31	32	87.31	89.51	92.02	94.60	96.97	98.42
32	33	87.97	90.17	92.70	95.29	97.69	99.16
33	34	88.61	90.83	93.36	95.97	98.39	99.87
34	35	89.25	91.47	94.01	96.64	99.08	100.58
35	36	89.88	92.10	94.65	97.29	99.75	101.26
36	37	90.50	92.72	95.27	97.93	100.41	101.93
37	38	91.09	93.33	95.91	98.59	101.07	102.59
38	39	91.67	93.94	96.55	99.23	101.72	103.25
39	40	92.24	94.54	97.17	99.87	102.37	103.89
40	41	92.80	95.14	97.79	100.51	103.01	104.54
41	42	93.36	95.72	98.40	101.13	103.65	105.17
42	43	93.91	96.30	99.00	101.76	104.28	105.81
43	44	94.46	96.87	99.60	102.37	104.90	106.43
44	45	94.99	97.44	100.19	102.98	105.52	107.06
45	46	95.53	98.00	100.78	103.59	106.14	107.68
46	47	96.06	98.56	101.36	104.19	106.75	108.30
47	48	96.58	99.11	101.94	104.78	107.36	108.91
48	49	97.10	99.66	102.51	105.38	107.97	109.52
49	50	97.62	100.2	103.08	105.97	108.57	110.13
50	51	98.14	100.74	103.65	106.55	109.17	110.74
51	52	98.65	101.28	104.21	107.14	109.77	111.35
52	53	99.16	101.82	104.77	107.72	110.37	111.95
53	54	99.66	102.35	105.33	108.30	110.96	112.55
54	55	100.17	102.88	105.88	108.87	111.55	113.16
55	56	100.67	103.41	106.43	109.45	112.15	113.76
56	57	101.17	103.93	106.99	110.02	112.74	114.36
57	58	101.67	104.46	107.53	110.59	113.33	114.96
58	59	102.17	104.98	108.08	111.16	113.92	115.56
59	60	102.67	105.5	108.63	111.73	114.5	116.16
60	61	103.17	106.03	109.18	112.3	115.09	116.75
61	62	103.67	106.55	109.72	112.87	115.68	117.35
62	63	104.17	107.07	110.26	113.43	116.27	117.95
63	64	104.67	107.59	110.81	114	116.85	118.55
64	65	105.17	108.11	111.35	114.56	117.44	119.15
65	66	105.66	108.62	111.89	115.13	118.02	119.75
66	67	106.16	109.14	112.43	115.69	118.61	120.34
67	68	106.66	109.66	112.97	116.26	119.19	120.94
68	69	107.16	110.18	113.51	116.82	119.78	121.54
69	70	107.66	110.7	114.05	117.38	120.36	122.14
70	71	108.16	111.21	114.59	117.94	120.94	122.74
71	72	108.66	111.73	115.12	118.5	121.53	123.33
72	73	109.16	112.25	115.66	119.06	122.11	123.93
73	74	109.66	112.76	116.2	119.62	122.69	124.53
74	75	110.16	113.28	116.73	120.18	123.27	125.12
75	76	110.66	113.79	117.27	120.74	123.85	125.72
76	77	111.16	114.31	117.8	121.29	124.43	126.31
77	78	111.66	114.82	118.33	121.85	125.01	126.9
78	79	112.16	115.34	118.87	122.4	125.59	127.5
79	80	112.66	115.85	119.4	122.96	126.16	128.09
80	81	113.16	116.36	119.93	123.51	126.74	128.68
81	82	113.65	116.87	120.46	124.06	127.31	129.27
82	83	114.15	117.38	120.98	124.61	127.88	129.85
83	84	114.64	117.88	121.51	125.15	128.45	130.44
84	85	115.14	118.39	122.03	125.7	129.02	131.02
85	86	115.63	118.89	122.55	126.24	129.59	131.6
86	87	116.11	119.39	123.07	126.78	130.15	132.18

Appendix D: BLOOD PRESSURE REFERRAL LEVELS BASED ON AGE AND PERCENTILE LENGTH/HEIGHT, GIRLS 1-6 YEARS.

Child Blood Pressure Values

Girls - Age 1 (11 Months +)

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<52	52-55	56-69	 70
< 97	1	2	3	4
97-99	2	2	3	4
100-113	3	3	3	4
 114	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<53	53-56	57-69	 70
< 97	1	2	3	4
97-100	2	2	3	4
101-113	3	3	3	4
 114	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<53	53-56	57-70	 71
< 98	1	2	3	4
98-101	2	2	3	4
102-114	3	3	3	4
 115	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<54	54-57	58-70	 71
< 100	1	2	3	4
100-103	2	2	3	4
104-116	3	3	3	4
 117	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<55	55-58	59-71	 72
< 101	1	2	3	4
101-104	2	2	3	4
105-117	3	3	3	4
 118	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<55	55-58	59-72	 73
< 102	1	2	3	4
102-105	2	2	3	4
106-118	3	3	3	4
 119	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<56	56-59	60-72	 73
< 103	1	2	3	4
103-106	2	2	3	4
107-119	3	3	3	4
 120	4	4	4	4

Girls - Age 2

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<57	57-60	61-74	 75
< 98	1	2	3	4
98-101	2	2	3	4
102-114	3	3	3	4
 115	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<58	58-61	62-75	 76
< 99	1	2	3	4
99-102	2	2	3	4
103-115	3	3	3	4
 116	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<58	58-61	62-75	 76
< 100	1	2	3	4
100-103	2	2	3	4
104-116	3	3	3	4
 117	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<59	59-62	63-75	 76
< 101	1	2	3	4
101 - 104	2	2	3	4
105-117	3	3	3	4
 118	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<60	60-63	64-76	 77
< 103	1	2	3	4
103-106	2	2	3	4
107-119	3	3	3	4
 120	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<61	61-64	65-77	 78
< 104	1	2	3	4
104-107	2	2	3	4
108-120	3	3	3	4
 121	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<61	61-64	65-77	 78
< 105	1	2	3	4
105-108	2	2	3	4
109-121	3	3	3	4
 122	4	4	4	4

Girls - Age 3

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<61	61-64	65-78	 79
< 100	1	2	3	4
100-103	2	2	3	4
104-116	3	3	3	4
 117	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<62	62-65	66-78	 79
< 100	1	2	3	4
100-103	2	2	3	4
104-116	3	3	3	4
 117	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<62	62-65	66-79	 80
< 102	1	2	3	4
102-104	2	2	3	4
105-118	3	3	3	4
 119	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<63	63-66	67-79	 80
< 103	1	2	3	4
103 - 106	2	2	3	4
107-119	3	3	3	4
 120	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<64	64-67	68-80	 81
< 104	1	2	3	4
104-107	2	2	3	4
108-120	3	3	3	4
 121	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<64	64-67	68-81	 82
< 106	1	2	3	4
106-108	2	2	3	4
109-121	3	3	3	4
 122	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<65	65-68	69-81	 82
< 106	1	2	3	4
106-109	2	2	3	4
110-122	3	3	3	4
 123	4	4	4	4

Girls - Age 4

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<64	64-67	68-75	 76
< 101	1	2	3	4
101-104	2	2	3	4
105-111	3	3	3	4
 112	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<64	64-67	68-75	 76
< 102	1	2	3	4
102-105	2	2	3	4
106-112	3	3	3	4
 113	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<65	65-68	69-75	 76
< 103	1	2	3	4
103-106	2	2	3	4
107-113	3	3	3	4
 114	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<66	66-69	70-76	 77
< 104	1	2	3	4
104-107	2	2	3	4
108-114	3	3	3	4
 115	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<67	67-70	71-77	 78
< 106	1	2	3	4
106-109	2	2	3	4
110-116	3	3	3	4
 117	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<67	67-70	71-78	 79
< 107	1	2	3	4
107-110	2	2	3	4
111-117	3	3	3	4
 118	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<68	68-71	72-78	 79
< 108	1	2	3	4
108-111	2	2	3	4
112-118	3	3	3	4
 119	4	4	4	4

Girls - Age 5

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<66	66-69	70-77	 78
< 103	1	2	3	4
103-106	2	2	3	4
107-113	3	3	3	4
 114	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<67	67-70	71-77	 78
< 103	1	2	3	4
103-106	2	2	3	4
107-113	3	3	3	4
 114	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<67	67-70	71-78	 79
< 105	1	2	3	4
105-107	2	2	3	4
108-115	3	3	3	4
 116	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<68	68-71	72-78	 79
< 106	1	2	3	4
106-109	2	2	3	4
110-116	3	3	3	4
 117	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<69	69-72	73-79	 80
< 107	1	2	3	4
107-110	2	2	3	4
111-117	3	3	3	4
 118	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<69	69-72	73-80	 81
< 109	1	2	3	4
109-111	2	2	3	4
112-119	3	3	3	4
 120	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<70	70-73	74-80	 81
< 109	1	2	3	4
109-112	2	2	3	4
113-119	3	3	3	4
 120	4	4	4	4

Girls - Age 6

Percentile of length/height = Less than 10 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<68	68-71	72-85	 86
< 104	1	2	3	4
104-107	2	2	3	4
108-120	3	3	3	4
 121	4	4	4	4

Percentile of length/height = 10-24 %

Systolic (mm Hg)	Diastolic (mm Hg)
	<68	68-71	72-85	 86
< 105	1	2	3	4
105-108	2	2	3	4
109-121	3	3	3	4
 122	4	4	4	4

Percentile of length/height = 25 - 49%

Systolic (mm Hg)	Diastolic (mm Hg)
	<69	69-72	73-85	 86
< 106	1	2	3	4
106-109	2	2	3	4
110-122	3	3	3	4
 123	4	4	4	4

Percentile of length/height = 50 - 74%

Systolic (mm Hg)	Diastolic (mm Hg)
	<70	70-73	74-86	 87
< 108	1	2	3	4
108-110	2	2	3	4
111-124	3	3	3	4
 125	4	4	4	4

Percentile of length/height = 75 - 89%

Systolic (mm Hg)	Diastolic (mm Hg)
	<70	70-73	74-87	 88
< 109	1	2	3	4
109-112	2	2	3	4
113-125	3	3	3	4
 126	4	4	4	4

Percentile of length/height = 90 - 94%

Systolic (mm Hg)	Diastolic (mm Hg)
	<71	71-74	75-88	 89
< 110	1	2	3	4
110-113	2	2	3	4
114-126	3	3	3	4
 127	4	4	4	4

Percentile of length/height = 95% and higher

Systolic (mm Hg)	Diastolic (mm Hg)
	<72	72-75	76-88	 89
< 111	1	2	3	4
111-114	2	2	3	4
115-127	3	3	3	4
 128	4	4	4	4

APPENDIX E-1: FEMALE RECUMBENT LENGTH (AGE 11.0-24 M) PERCENTILES

Length (Age 11.0 m -36 m) Percentiles
If age in months is greater than or =	and less than	P10 - P24	P25 - P49	P50 - P74	P75 - P89	P90 - P94	P95 - >
11	12	69.54	71.07	72.77	74.47	76.00	76.92
12	13	70.72	72.28	74.02	75.75	77.31	78.25
13	14	71.85	73.44	75.22	76.99	78.59	79.54
14	15	72.94	74.57	76.38	78.19	79.82	80.80
15	16	74.00	75.66	77.51	79.38	81.02	82.02
16	17	75.02	76.72	78.61	80.49	82.19	83.20
17	18	76.02	77.75	79.67	81.59	83.32	84.36
18	19	76.99	78.75	80.71	82.67	84.43	85.48
19	20	77.93	79.72	81.72	83.71	85.51	86.58
20	21	78.84	80.67	82.70	84.74	86.56	87.66
21	22	79.73	81.60	83.67	85.73	87.60	88.71
22	23	80.61	82.50	84.60	86.71	88.60	89.74
23	24	81.45	83.38	85.52	87.66	89.60	90.74
24	25	82.28	84.24	86.42	88.59	90.55	91.72

APPENDIX E-2: FEMALE STANDING HEIGHT (AGE 24M +) PERCENTILES

Height (Age 24 m +) Percentiles
If age in months is greater than or =	and less than	P10 - P24	P25 - P49	P50 - P74	P75 - P89	P90 - P94	P95 - >
24	25	80.92	83.04	85.4	87.75	89.86	91.13
25	26	81.74	83.89	86.29	88.68	90.84	92.12
26	27	82.54	84.73	87.16	89.59	91.77	93.08
27	28	83.32	85.53	88	90.46	92.68	94.01
28	29	84.08	86.32	88.81	91.3	93.55	94.9
29	30	84.82	87.07	89.58	92.11	94.39	95.76
30	31	85.52	87.8	90.33	92.88	95.19	96.58
31	32	86.21	88.49	91.05	93.63	95.96	97.36
32	33	86.86	89.16	91.74	94.34	96.7	98.12
33	34	87.48	89.8	92.4	95.02	97.4	98.84
34	35	88.08	90.41	93.03	95.67	98.08	99.53
35	36	88.65	91	93.63	96.3	98.73	100.19
36	37	89.2	91.56	94.21	96.9	99.35	100.83
37	38	89.75	92.12	94.8	97.51	99.98	101.47
38	39	90.29	92.68	95.37	98.11	100.6	102.11
39	40	90.82	93.23	95.95	98.71	101.23	102.75
40	41	91.35	93.78	96.52	99.3	101.84	103.38
41	42	91.88	94.32	97.08	99.89	102.46	104.01
42	43	92.4	94.87	97.65	100.48	103.07	104.64
43	44	92.93	95.41	98.21	101.07	103.69	105.27
44	45	93.45	95.95	98.78	101.66	104.3	105.9
45	46	93.98	96.49	99.34	102.25	104.91	106.53
46	47	94.5	97.03	99.9	102.84	105.53	107.16
47	48	95.03	97.58	100.47	103.42	106.14	107.79
48	49	95.55	98.12	101.03	104.02	106.76	108.42
49	50	96.08	98.66	101.6	104.61	107.37	109.06
50	51	96.61	99.21	102.17	105.2	107.99	109.69
51	52	97.14	99.76	102.74	105.8	108.61	110.33
52	53	97.67	100.31	103.31	106.39	109.23	110.97
53	54	98.21	100.86	103.89	106.99	109.86	111.61
54	55	98.75	101.42	104.46	107.59	110.48	112.25
55	56	99.29	101.97	105.04	108.2	111.11	112.89
56	57	99.83	102.53	105.62	108.8	111.74	113.54
57	58	100.37	103.09	106.2	109.41	112.37	114.18
58	59	100.92	103.65	106.79	110.01	113	114.83
59	60	101.46	104.22	107.37	110.62	113.64	115.48
60	61	102.01	104.78	107.96	111.23	114.27	116.13
61	62	102.56	105.35	108.54	111.84	114.91	116.78
62	63	103.11	105.92	109.13	112.45	115.54	117.43
63	64	103.66	106.48	109.72	113.067	116.18	118.08
64	65	104.21	107.05	110.31	113.68	116.81	118.73
65	66	104.76	107.62	110.9	114.29	117.45	119.39
66	67	105.31	108.19	111.49	114.9	118.08	120.04
67	68	105.87	108.76	112.076	115.52	118.72	120.69
68	69	106.42	109.32	112.66	116.13	119.35	121.33
69	70	106.96	109.89	113.25	116.74	119.99	121.98
70	71	107.51	110.45	113.84	117.35	120.62	122.63
71	72	108.06	111.02	114.42	117.95	121.25	123.27
72	73	108.6	111.58	115.01	118.56	121.87	123.91
73	74	109.15	112.14	115.59	119.16	122.5	124.55
74	75	109.69	112.7	116.16	119.76	123.12	125.18
75	76	110.23	113.26	116.74	120.36	123.74	125.81
76	77	110.76	113.81	117.31	120.95	124.35	126.44
77	78	111.29	114.36	117.88	121.54	124.96	127.06
78	79	111.82	114.9	118.45	122.13	125.57	127.68
79	80	112.35	115.45	119.01	122.72	126.17	128.3
80	81	112.87	115.98	119.57	123.29	126.77	128.91
81	82	113.39	116.52	120.13	123.87	127.36	129.51
82	83	113.9	117.05	120.68	124.44	127.95	130.11
83	84	114.41	117.58	121.22	125.01	128.53	130.7
84	85	114.91	118.1	121.76	125.57	129.11	131.29

Public reporting burden for this collection of information is estimated to average 10 minutes per response, including the time for reviewing instructions, searching existing data sources, gathering and maintaining the data needed, and completing and reviewing the collection of information.  An agency may not conduct or sponsor, and a person is not required to respond to, a collection of information unless it displays a currently valid OMB control number.  Send comments regarding this burden estimate or any other aspect of this collection of information, including suggestions for reducing this burden, to: NIH, Project Clearance Branch, 6705 Rockledge Drive, MSC 7974, Bethesda, MD 20892-7974, ATTN: PRA (0925-0593*).  Do not return the completed form to this address.
