Social Security Administration
BEVE/MRC



User Interface Design Specification

Last Saved: 10 May, 2010


OMB Attestation Addition

2.5.4
























Verizon Business Confidential & Proprietary.

This documentation is extremely sensitive; please limit distribution. No part of this document may be photocopied, disclosed, or otherwise provided to third parties without the consent of Verizon Business.

Document History

Date

Spec

App

Summary of Changes

Revised by

4/14/04

.01

1.0

Initial version

Robby Kilgore

4/16/04

.02

1.0

Sample Calls updated

Robby Kilgore

4/20/04

.03

1.0

Updated sample calls post review

Robby Kilgore

4/20/04

.04

1.0

Begin DM Tables

Robby Kilgore

4/21/04

.05

1.0

Adding Name 2.0 OSDM Tables

Robby Kilgore

4/21/04

.06

1.0

Added 2.0 plus post Name states

Robby Kilgore

4/22/04

.07

1.0

Added Visio details for main speech application

Robby Kilgore

4/22/04

.08

1.0

Debugged tables

Robby Kilgore

4/22/04

.09

1.0

Consolidated exit tables, synced Visio flows, updated demographics slightly.

Robby Kilgore

4/23/04

.10

1.0

Added global handoffs, reconciled sample call text.

Robby Kilgore

4/23/04

.11

1.0

Included feedback from Joe and other tweaks for Draft release

Robby Kilgore

4/23/04

.12

1.0

Added Joe’s changes for Draft

Robby Kilgore

4/26/04

.13

1.0

Folded in comments from CPT review call

Robby Kilgore

4/28/04

.20

1.0

Changed Name 2.0 to 1.12 interaction model

Robby Kilgore

4/28/04

.21

1.0

Comb through for any bugs introduced by changes to interaction model

Robby Kilgore

4/28/04

.22

1.0

Reviewed and tracked changes with Joe Farhat and Jon Bloom

Robby Kilgore

4/29/04

.23

1.0

Folded in changes from last review

Robby Kilgore


Date

Spec

App

Summary of Changes

Revised by

4/29/04

1.0

1.0

Ready release for client review

Robby Kilgore

4/30/04

1.01

1.0

Received input from SSA / CPT review call

Robby Kilgore

5/2/04

1.02

1.0

Updated spec to reflect input from SSA / CPT review call

Robby Kilgore

5/4/04

1.03

1.0

Added MaxHelp hand-off prompts and miscellaneous other small changes covered in phone meeting 5/4/04

Robby Kilgore

5/5/04

1.04

1.0

Updated sample calls

Robby Kilgore

5/5/04

1.05

1.0

Small changes to sample call and removal of “Agent” verbiage.

Robby Kilgore

5/19/04

1.06

1.0

Reconciled the document to reflect small text changes from the recording sessions as well as flagging marking global vs. local apologies.

Robby Kilgore

5/27/04

1.07

1.0

Reconciled prompt text with recordings.

Robby Kilgore

6/11/04

1.11

1.0

Reconciled against bugs, plus added changes from UT

Robby Kilgore

6/14/04

1.12

1.0

Created new document for safety sake. Removed punctuation from Grammars

Robby Kilgore

6/15/04

1.13

1.0

Updated based on review with SSA / MCI / CPT

Joe Farhat

6/16/04

1.14 /

1.15

1.0

Updated to resolve CR1582, 1583, 1584, 1585, 1590, 1591, 1592, 1593, 1613, and 1624. Minor update to nomatch prompts in 1040_ConfirmName

Joe Farhat

6/17/04

1.16

1.0

Tiny tweak to the prompt text in 1400080, Added note about Confirmation Grammars

Robby Kilgore

6/30/04

1.18 / 1.19.1

1.0

Fixing up the last few CRs

Robby Kilgore / Joe Farhat

8/9/04

1.20

1.0

Revisions based on Pilot tuning report.

Robby Kilgore

8/10/04

1.21

1.0

Finalized UI Doc changes post review with SSA

Robby Kilgore

9/15/04

1.23

1.0

Adjustments from Tuning Report #2

Robby Kilgore

10/25/04

1.24

1.0

Adjustments from final tuning

Robby Kilgore

10/28/04

1.25

1.0

Clarified deactivation of global agent grammar in 1000_SayLastName and 1020_SayFirstName

Joe Farhat

11/04/04

1.26

1.0

Final tweaks to verbiage to match recordings

Robby Kilgore

11/05/04

1.27

1.0

Last minute corrections and acceptance of all changes
FINAL VERSION

Robby Kilgore


Date

Spec

App

Summary of Changes

Revised by

6/23/05

2.0

1.0

Changes based on tuning analysis and recommendations of June 2005.

1. 1020_SayFirstName – change Initial prompt to discourage spelling here.

2. 1040_ConfirmName – add more synonyms for Yes and No.

3. 1060_GetMistake – add synonym for Both.

4. DM9000_Check_For_Alt_Name – Change Initial prompt to discourage barge in and speaking of a name rather than Yes or No. Also turn off barge-in.

5. DM11000_ReturnToMain_or_HangUP – no action – rejected recommendation of adding Yes/Yeah as synonyms for Main Menu and No as synonym for Goodbye. The number of occurrences is low. Yes seems just as likely a response to Goodbye as to Main Menu. The cost of failure to the caller in this DM is very low.

6. Eliminated useless Appendix A.

7. PP2000_Standard_Greeting – Added new prompts for the case when these services are invoked from the Speak Freely N8NN rather than the old DTMF N8NN.


Paul Sawyer

15 Feb 06

2.1

1.0

1. Remove restriction on date of birth in DM5000.

2. Add support for blocked accounts. Affects PP1500, BR8000, DM11000.


Paul Sawyer

23 Mar 06

2.2

1.0

1. Corrected 500_EntryPrompt module for subsequent module when Spelling – TRUE and names_to_collect = LAST or LAST_FIRST

2.Fixed wording of default_name_spelllast_collection_noinputprompts1 in 1090_RespellLast

3. Fixed wording of default_name_spellfirst_collection_noinputprompts2 in 1070_RespellFirst

4. Fixed wording of default_name_spelllast_collection_reprompts1 in 1090_respellLast

5. Fixed wording of default_name_getmistake_collection_reprompts2 in 1060_GetMistake

6. Fixed wording of default_name_sayfirst_collection_nomatchprompts1 in 1020_SayFirstName


Phil Profili

18 Apr 07

2.2

1.34

1. Removed references to BR8100

2. Added new state, DB3050

3. Updated DM3000 and BR3100

Sean Stallings

VZB

23 Apr 07

2.2

1.35

1. Updated 1000_SayLastName

2. Updated 1020_SayFirstName

3. Removed Confirmation logic from 1060_GetMistake

4. Updated PP2000

5. Removed PP9999

6. Updated BR3100


Sean Stallings

VZB

21 May 07

2.2

1.36

Updated 1060 GetMistake

Sean Stallings

VZB

05 July 07

2.2

1.37

Updated DM 4000, removed ”great” from 50201

Sean Stallings

VZB

10 July 07

2.2

1.38

Replaced wording in states 500 through 1090 with wording from corresponding KBA prompts.

Added developers notes to states 500 through 1090 stating that these states now share prompting with KBA.

Sean Stallings

VZB

11 July 07

2.2

1.39

Corrected some changes made in states 500 through 1090

Sean Stallings

VZB

12 July 07

2.2

1.40

Incorporated new message numbers in 6.1 Timeouts and Retries, DM 4000 and DM 9000

Sean Stallings

VZB

19 July 07

2.2

1.41

Updated 50206, 50307, 50308, 50312, 50367, 10062

Carol Cummings

VZB

21 July 07

2.2

1.42

Updated

Carol Cummings

VZB

08 August 07

2.2

1.43

Corrected DM 11000 to show that only Global Agent Command is disabled

Sean Stallings

VZB

15 Aug 07

2.2

1.44

Corrected prompting in message number 50204

Sean Stallings

VZB

08 Oct 07

2.2

1.45

Removed msg. 50368 from 1070

Removed msg. 50382, from 1090

Sean Stallings

VZB

31 Oct 07

2.2

1.46

Broke message 10054 into two parts, 10054 and 10088. Allowed barge in= True for 10088.

Sean Stallings

VZB

3 Mar 08

2.2

1.47

Added Privacy paragraph to chapter 6 Global Behavior

Added BR 1900

Added BR 3999

Added BR 4005

Added 400

Updated DM 4000, 5000, 1000, 1010, 1020, 1030, 1070, 1090 and 9000; Added confidential flag setting data to module notes

Sean Stallings

VZB

06 Mar 08

2.2

1.48

Corrected broken hyperlink in 6.4 Help Prompts

Updated P2000, adjusted the wording to reflect the fact that we may or may not be collecting 5 pieces of information.

Sean Stallings

VZB

10 Mar 08

2.2

1.49

Updated BR 1900, BR 3999, 400-Name Check Condition; ; Corrected reporting information for “if else” conditions.

Sean Stallings

VZB

21 Mar 08

2.2

1.5

Corrected reporting string in BR3999 and 400

Sean Stallings

VZB

1 Apr 08

2.2

1.51

Updated reporting string for first and last name re-use

Sean Stallings

VZB

4 Apr 08

2.2

1.52

Updated BR 1900, if callers information is complete callers now route to PP 6000.

Added BR 4005.

Clarified wording for BR1900 Check Null Condition

Sean Stallings

VZB

11 Apr 08

2.2

1.53

In order to assure that re-use items are properly reported, in Check Null Condition, if TVDC items to collect = 0, the call must then route to the next Check Condition Module.

Sean Stallings

VZB

17 Apr 08

2.2

1.54

Updated Module 9000 Added “Barge in” column to the prompt table, barge in is set to “false” for initial prompt, “true” for all others.

Broke message 10054 into two parts, 10054 and 10088.

Sean Stallings

VZB

21 Apr 08

2.2

1.55

Corrected broken link in table of contents.

Corrected reporting strings for BR3999, BR4005, Module 400, BR5500

Sean Stallings

VZB

2 May 08

2.2

1.56

Updated reporting strings for BR3999, BR4005, Module 400, BR5500

Sean Stallings

VZB

7 May 08

2.2

1.57

Updated DM 9000, renumbered message 10088 to 10092, to prevent overlap.

Sean Stallings

VZB

13 June 08

2.2

1.58

Updated Module 4005, module is now correctly named DOB_Check_Condition.

Updated module 5000, ‘entering from’ field now shows entering from 4005 DOB_Check_Condition.

Sean Stallings

VZB

23 June 08

2.2

1.59

Updated module 1090_RespellLast, ‘Entering From’ field no longer points to module 1070_RespellLast. This resolves ticket 20603.

Sean Stallings

VZB

4 August 08

2.2

1.60

Updated module 4000_Get_SS_Number.

To improve capture process the wording of all prompts has been changed to match SSN capture in KBA.

Audio for Initial prompt, message 54201, changed to match KBA 50201

Audio for Retry 1 prompt, message 54202, changed to match KBA 50202.

Corrected reporting tags in modules BR3999, BR4005 and 400. Removed spaces after commas.

Corrected dead hyperlink issue in “Entering From” fields found in module 1000, modules 3050 through 9000, and modules 11000 through 14000.

Updated Modules 4000 and 5000, updated ‘results’ column in the confirmation ‘field’ for Retry 1 and Timeout 1. Now shows an example of the wording a caller would hear, not the specific data field.

Updated modules 1000, 1010, 1020, 1030 and 1040. Corrected references to 500_Intro. Now reads ‘500_EntryPrompt’.

Updated Module 4000, now shows entering from Module 3999.

Sean Stallings

VZB

21 August 08

2.2

1.61

Highlighted Barge-in changes in pink

Sean Stallings

VZB

09September 08

2.2

2.0

Updated DM 3000, on ‘no’ condition call should route to DB 3050.

BBN Findings Effort

  1. Updated section 6.1 Time-outs and Retries, updated wording for confirmation retry 2, changed message 50345 to 50347.

  2. Updated DM3000_CheckAOR, updated wording for retry 2, message 30022

  3. Updated module 1040, for retry 2 replaced message 50345 with 50347.

  4. Updated module 9000, updated message 10056

  5. Highlighted all BBN Findings changes in Green


Sean Stallings

VZB

25 September 08

2.2

2.1

Added Verizon Business proprietary statement to title page and all page footers.

Sean Stallings

VZB

02

October

08

2.2

2.2

Updated 6.1 highlighted the BBN change to the global retry 2 in Green.

Updated 1000_SayLastName, added condition for ‘Failure and Alt Name’ which now routes to PP6000 – this resolves ticket 22408. Added new wording for Other Last Name, retry 1,message 50310, caller will now only be asked to spell their other last name.

Updated PP6000, now shows as entering in from 1000_SayLastName.


Sean Stallings

VZB

01

December

08

2.2

2.3

COADD/BEVE-MRC Tuning 2 Effort-Recommendations From Nuance

  1. Updated module 1070, added entry to ‘Module Notes’ stating that confidence levels for this module should be set to .400.

  2. Updated module 1090, added entry to ‘Module Notes’ stating that confidence levels for this module should be set to .400


Sean Stallings

VZB

29

January

09

2.2

2.4

Updated Header

Sean Stallings

VZB

22, May

09

2.2

2.5

FOAP Effort

Updated module PP 12000, added flag check and routing for FOAP condition.

Sean Stallings

VZB

25 June 09

2.2

2.5.1

Corrected broken links in DM’s 1030 and PP10000. Fixed typographical errors in DM’s 4000 and 500.

Kim Rothlis

VzB

23 March 10

2.2

2.5.2

Global Commands and Global Prompts (section 6.6), added Action for ‘agent’ command.

OMB Attestation Addition Change

Added DM 2988 Attestation Flag Check and DM2990_AttestationYN between modules P2000_Standard_Greeting and DM3000_Check_AOR

Updated modules P2000 and DM3000 with correct routing/hyperlinks.

Updated Section 5.2, High-Level Call Flow Diagram with the added DM’s.



MISC:

Corrected entering from field for module PP1500_Getting Help_Operator


Kim Rothlis

VzB

29 April 10



05 May 10


2.2

2.5.3

Issue Fix (TBEV-5): Updated module 1070 RespellFirst, message 50367 with correct wording.

2990 – AttestationYN – Updated Success2 with MaxHelp


Kim Rothlis, VzB

Carol Cummings

VzB


10 May 2010

2.2

2.5.4

Updated PP13000_Goodbye , message #10078 to reflect ‘as built’ wording.

Kim Rothlis, VzB


Chapter 1: Table of Contents

Chapter 1: Table of Contents 3

Chapter 2: Background and Motivation 3

2.1 Executive Summary 3

2.1.1 What the application does 3

2.1.2 Social Security Administration’s goals 3

2.1.3 Callers’ goals 3

2.2 Aesthetics 3

2.3 Open Issues 3

Chapter 3: About the Callers 3

3.1 Introduction 3

3.2 Demographics Data 3

3.3 Caller Archetypes 3

Chapter 4: Call Examples 3

4.1 Sample Call Design Considerations 3

4.1.1 Verboseness 3

4.1.2 Confirmation Strategy: 3

4.1.3 In Session Tracking: 3

4.1.4 Longevity: 3

4.2 Call #1: No Collection Problems 3

4.3 Call #2: Handling Hyphenated Name with Spelling 3

4.4 Call #3: MRC - Misrecognized Name plus Alternate Name 3

4.5 Call #4: A Rejected Request 3

Chapter 5: Call-Flow Diagrams 3

5.1 Legend for the call-flow diagrams 3

5.2 High-Level Call Flow Diagram 3

5.3 Outbound Transfer Logic 3

5.4 Name OSDM High-Level Diagram 3

5.5 Name DM Diagram – Default Configuration 3

5.6 Name DM Flow Diagram – Collecting Last Name Only. 3

Chapter 6: Global Behavior 3

6.1 Time-outs and Retries 3

6.2 Global Default Settings 3

6.3 Privacy 3

6.4 Help prompts 3

6.5 Default Confirmation Grammars 3

6.6 Global Commands and Global Prompts 3

Global Commands Vocabulary 3

6.7 DTMF Collection 3

6.7.1 General DTMF Usage 3

6.7.2 Termination of digit strings using the pound sign 3

6.7.3 Invalid dtmf input should be rejected 3

6.7.4 End-of-dtmf timeout 3

6.7.5 Key-ahead 3

6.8 Digit-String Playback 3

6.9 Event Logging 3

6.10 Internal DialogModule Functionality 3

Chapter 7: Detailed Dialog Specification 3

7.1 How to Read the Call-Flow Tables 3

7.2 Call-Flow Tables 3

DB0000_Ping_System 3

BR1000_System_And_Operator_Availability 3

PP1500_Getting_Help_Operator 3

BR1900 Check Null Condition 3

P2000_Standard_Greeting 3

BR2988-Attestation Flag Check 3

DM2990_AttestationYN 3

DM3000_Check_AOR 3

DB3050_Check_AOR_Ping 3

BR3100_AfterHours_Check 3

BR3999 Social Security Check Condition 3

4000_Get_SS_Number 3

BR4005 DOB Check Condition 3

5000_Get_DOB 3

400- Name Check Condition 3

500_EntryPrompt 3

1000_SayLastName 3

1010_SpellLastName 3

1020_SayFirstName 3

1030_SpellFirstName 3

1040_ConfirmName 3

1050_ConfirmationApology 3

1060_GetMistake 3

1070_RespellFirst 3

1090_RespellLast 3

3000_ExitFailurePrompt 3

4000_ExitSuccessPrompts 3

BR5500_Alt_Name_Collected 3

PP6000_Ready_To_Submit 3

DB7000_SubmitRequest 3

BR8000_DB_Request_Validate_1st 3

DM9000_Check_For_Alt_Name 3

PP10000_Task_Complete 3

DM11000_ReturnToMain_or_HangUP 3

PP12000_Thanks_Before_Return 3

PP13000_Goodbye 3

DM14000_Post_Options 3


Chapter 2: Background and Motivation

2.1Executive Summary

The Social Security Administration serves callers currently receiving benefits as well as the general population with self-service and informational assistance. SSA is looking for ways to improve self-service options for both calling populations. Existing self-service options are currently available from the SSA web site or via the SSA N8NN telephone interface. SSA would like to enhance the telephone based self-service options to include advanced speech with a real-time request processing. The self-service functions contained within the scope of this project are 1) Automated replacement Medicare Card service 2) Automated benefit verification letter service.

2.1.1What the application does

  • Self-Serve Medicare Card Replacement Requests – Use of this application requires that you currently receive Medicare Benefits, or that you are eligible to receive benefits. This application will allow callers to request a new or replacement Medicare Card, and will receive approximately 785K calls annually.


  • Self-Serve Benefit Verification Requests – Use of this application is for Social Security beneficiaries and will allow callers to request a statement of Social Security benefit verification letter for various purposes. This application will receive approximately 1.9 million calls annually.

2.1.2Social Security Administration’s goals

Primary goals of the speech application are to:

  • Provide universal access to the SSA’s automated services by providing an access channel for callers including the visually impaired.

  • Offer real-time fulfillment of Benefit Verification letter requests or Medicare Replacement Card requests without needing to transcribe information collected by the existing automated Touch Tone system. Doing so will eliminate transcription time and transcription errors, as well as minimize the time lag between callers making the request and transcription of the request. Transcription time introduces delays in mailing out the forms, resulting in callers calling back to find out if their forms have been mailed.

One business objective for the speech application is cost reduction. Automating calls and minimizing the number of calls to SSA agents is the primary mechanism towards this goal. As such, the application will be implemented in a way to streamline and automate requests.

2.1.3Callers’ goals

Callers are seeking simple self service.

2.2Aesthetics

Jill converses with caller in a clean yet informal, role-appropriate female voice. She is friendly, competent and resourceful. Even when she’s unable to complete a caller’s request, she usually provides helpful suggestions on how they can proceed.

2.3Open Issues


Chapter 3: About the Callers

3.1Introduction

The design of the user interface is driven, in part, by ScanSoft’s understanding of the population of callers to the system. Generally, callers will access the system for one of two reasons. They are either Medicare recipients looking to replace a Medicare card or Social Security recipients looking to receive a letter verifying their Social Security benefits. These two caller populations will call an 800 number to access the N8NN Main Menu system, and will eventually route themselves to the new BEVE/MRC speech application to request a replacement Medicare Card or request a verification of Social Security benefits.


It is presumed that all callers are first timers who will not call again.

3.2Demographics Data


General Population: Age of Recipients

Thirty nine million people are receiving benefits. Eight percent of them are disabled and range in age from 18 on up. The rest are 65 and older. There are also 8 million people of any age on Supplemental Security Income (SSI)





Caller Population: Age Distribution


BEVE: Of the 1.9 million annual callers,

66% are below 61 years of age.

MRC: Of the 785,000 callers requesting Medicare Replacement Cards, 66% are above 70 years of age.



The chart below shows the age distribution within the general US population. It is included here because it is assumed that the age distribution of the potential caller population roughly matches that of the general population.




Who are SSA beneficiaries?

  • Elderly (62+ years)
    35.8 million.
    Most likely have not had experience with VUI

  • Disabled (18+ years)
    3.12 Million
    ~8% of the population?

  • Low Income (18+)
    8 Million
    Supplemental Security Income (SSI)


3.3Caller Archetypes

J ames Richards

James is 67 years young, living in Grand Forks, North Dakota, 90 miles south of the Canadian border in eastern North Dakota. He has a small woodworking shop that’s attached to his garage. The bank has told him he needs to provide a verification letter from the SSA as proof of income for a home improvement loan.


J ane Preston-Blair

She is originally from Norwalk, Connecticut. She married her hometown sweetheart 39 years ago and they enjoyed 28 years of US Air Force life. They traveled all over before retiring and settling in North Carolina and that is where they call home. They have four wonderful daughters, who have rewarded them with seven beautiful grandchildren. Jane is requesting a verification letter. Her name is hyphenated. She’ll have to spell her name.


J ulia Davis (Brewer)

Born in Tampa Florida in 1948, Julia is disabled. She is a Medicare recipient and has also received Supplemental Security Income for the last several years. She is seeking a Replacement Medicare Card. Recently divorced; she is still listed under her ex-husband’s name. Her request fails on name mismatch and prompts for an alternate.


J im Trouble

This boy is a 15 year old wanna-be hacker, randomly trying Social Security numbers. He has no criminal intent, but is curious to see if he can retrieve social security numbers by using the system. The information he gives does not validate and his request is rejected out of hand. He will likely hang up when he learns he is being transferred to an operator.

Chapter 4: Call Examples

Callers arrive at this portion of the system by navigating through the N8NN main menu (via DTMF or Simple Speech) system. This can take a minute or more of DTMF interactions. The design of the interactions should accommodate this change in interaction style between the DTMF portion of the larger system and the “conversational” nature of the Speech Application. This may be accomplished through audio iconography, signposting and prompt text.


Callers have explicitly chosen the self service route, and are transferred to the speech system AFTER choosing either the “replacement card” or “verification letter” path. The Speech system will receive a flag signifying the task the caller is attempting to complete.


The call scenarios covered here include:


  • Benefits Verification Letter No errors.

  • Benefits Verification Letter Handling hyphenated name / spelling.

  • Medicare Card Request Listed under an alternate name.

  • Medicare Card Request Rejected request.

4.1Sample Call Design Considerations

4.1.1Verboseness

Jill’s audio and prompts are designed to accommodate the vast majority of callers whose VUI experience is either limited or perhaps nonexistent. The verbiage is designed to convey a clear mental model of how Jill behaves and what her capabilities are. This subtly helps callers remember to avoid chatty responses.

4.1.2Confirmation Strategy:

When designing speech interfaces, it’s often desirable to group confirmations together whenever possible; as in “So that’s Tuesday at 10AM for an hour. Right?”, but in Jill’s case, the data-types seem too unrelated. Because of the nature of her application, she’s forced to confirm at every turn. To justify this, she goes out of her way to acknowledge the importance of “getting things right”. Her prompting for confirmations becomes briefer as the caller progresses.

4.1.3In Session Tracking:

There are some prompts which exploit a simple form of in session tracking. Jill’s exit and hand-off phrases are context sensitive. That is, they specifically talk to the issues that have lead to the hand-off.

4.1.4Longevity:

Since the system is basically a one shot (first time is the last time) system where the task completion is more important than longevity, Jill is slightly biased towards relatively severe hand-holding to minimize dropout. Jill doesn’t advertising operator assistance, though she will eventually recommend it, as a path of last resort.


4.2Call #1: No Collection Problems

James Richards

James is 67 years young, living in Grand Forks, North Dakota, 90 miles south of the Canadian border in eastern North Dakota. He has a small woodworking shop that’s attached to his garage. The bank has told him he needs to provide a verification letter from the SSA as proof of income for a home improvement loan.


<Audio Icon>


Jill: Hello. You’ve reached the automated Benefits Verification service. Before I send out your letter, there are five questions I’ll need to confirm with you. We’ll go through them one at a time, and you can speak your answers.


To get started, I want to make sure I’ll be sending it to the right place. Have you had a change of address recently? Please say “YES” or “NO”.


Caller: No.


Jill: Great. Now - Please enter or say your nine digit Social Security number.


Caller: 1 2 3 – 3 9 – 8 1 4 5


Jill: This is important, so I want to make sure I have it right. Your social security number is: 1 2 3 – 4 5 – 6 7 8 9. Is that right?


Caller: Yes.


Jill: And what’s your date of birth? [Two second pause] For example, you can say…May 5th, 1957.


Caller: January 12th, 1931


Jill: Okay, so that’s: <January 12th, 1931>. Is that right?

Caller: Yeah.


Jill: Okay. Now, for your name, I’ll ask you to say it, then, I may ask you to spell it. Please say just your last name.


Caller: Richards


Jill: Thanks. Now I’ll need your first name. Please say it now.


Caller: James


Jill: Okay. Let me read that back to you to make sure I’ve got it right.
Last name: Richards, spelled R I C H A R D S.
First name, James, spelled J A M E S.
Did I get it right?


Caller: Yes.


Jill: Alright. We’re almost done. Before I send this off, do you have any other last name – for example, a professional or maiden name - that might be listed under this social security number?


Caller: No.


Jill: Okay. I’ve got everything we need. Hold on while I process your request.

Okay. You’re all set. You should receive your Benefits Verification Letter in the mail within two weeks.


If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.


Caller: Goodbye.


Jill: Okay Bye.


[Closing Audio Icon]


End Call

4.3Call #2: Handling Hyphenated Name with Spelling

Jane Preston-Blair

She is originally from Norwalk, Connecticut. She married her hometown sweetheart 39 years ago and they enjoyed 28 years of US Air Force life. They traveled all over before retiring and settling in North Carolina and that is where they call home. They have four wonderful daughters, who have rewarded them with seven beautiful grandchildren. Jane is requesting a verification letter. Her name is hyphenated. She’ll have to spell her name.


[Opening Audiomark]


Jill: Okay. Now, for your name, I’ll ask you to say it, then, I may ask you to spell it.

Please, say just your last name.


Caller: Preston-Blair


Jill: Could you spell that for me?


Caller: Yes. That’s P R E S T O N B L A I R


Jill: Thanks. Now I’ll need your first name. Please say it now.


Caller: Jane.


Jill: Okay. Let me read that back to you to make sure I’ve got it right.
Last name: Preston-Blair, spelled P R E S T O N B L A I R.
First name, Jane, spelled J A N E.
Did I get that right?


Caller: Yes.


Jill: Alright. We’re almost done. Before I send this off, do you have any other last name – for example, a professional or maiden name - that might be listed under this social security number?


Caller: No.


Jill: Okay. I’ve got everything we need. Hold on while I process your request.


Okay. You’re all set. You should receive your Benefits Verification Letter in the mail within two weeks.


If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.


Caller: Main Menu.


Jill: Sure. I’ll transfer you now.


[Closing Audio Icon]

4.4Call #3: MRC - Misrecognized Name plus Alternate Name

Julia Davis (Brewer)

Born in Tampa Florida in 1948, Julia is disabled. She is a Medicare recipient and has also received Supplemental Security Income for the last several years. She is seeking a Replacement Medicare Card. Recently divorced; she is still listed under her ex-husband’s name. Her request fails on name mismatch and prompts for an alternate.


Jill: Hello. You’ve reached the automated Medicare Replacement Card service. Before I send out your replacement card, there are five questions I’ll need to confirm with you. We’ll go through them one at a time, and you can speak your answers.


… …


Jill: Okay. Now, for your name, I’ll ask you to say it, then, I may ask you to spell it.

Please, say just your last name.


Caller: Davis


Jill: Thanks. Now I’ll need your first name. Please say it now.


Caller: Julia


Jill: Okay. Let me read that back to you to make sure I’ve got it right.
Last name: Davies, spelled D A V I E S.
First name, Julia, spelled J U L I A.
Did I get it right?


Caller: No.


Jill: Sorry about that. Which part is wrong? The first name, the last name or both?


Caller: The last name.


Jill: Please spell your last name, one letter at a time.


Caller: D A V I S


Jill: Got it. We’re almost done. Before I send this off, do you have any other last name – for example, a professional or maiden name - that might be listed under this social security number?


Caller: Yes. My ex-husband’s name was Brewer.


Jill: I’m sorry, but I didn’t understand. Would you like me to check under another last name? Please say “YES” or “NO”.


Caller: Yes.


Jill: Okay. Let’s try it. Give me the other last name.


Caller: Brewer


Jill: Could you spell that for me?


Caller: B R E W E R


Jill: Okay. Let me read that back to you to make sure I’ve got it right.
Last name: Brewer, spelled B R E W E R.
Did I get that right?


Caller: Yes


Jill: Okay. I’ve got everything we need. Hold on while I process your request.


Okay. You’re all set. You should receive your Medicare Replacement Card in the mail within four weeks. If you live in Puerto Rico, please allow eight weeks for delivery.


If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.


Caller: Main Menu


Jill: Sure. I’ll transfer you now.


[Closing Audio Icon]

4.5Call #4: A Rejected Request

Jim Trouble

This boy is a 15 year old wanna-be hacker, randomly trying Social Security numbers. The information he gives does not validate and his request is rejected out of hand.


<Audio Icon>

Jill: Hello. You’ve reached the automated Medicare Replacement Card service. Before I send out your replacement card, there are five questions I’ll need to confirm with you. We’ll go through them one at a time, and you can speak your answers.


To get started, I want to make sure I’ll be sending it to the right place. Have you had a change of address recently? Please say “YES” or “NO”.


Caller: No.


Jill: Great. Now - Please enter or say your nine digit Social Security number.


Caller: 1 2 3 – 4 5 – 6 7 8 9


Jill: This is important, so I want to make sure I have it right.
Your social security number is: 1 2 3 – 4 5 – 6 7 8 9. Is that right?


Caller: Yeah.


Jill: And what’s your date of birth? [Big pause] For example, you can say…May 5th, 1957.


Caller: January 22nd, 1989


Jill: Okay, so that’s: January 22nd, 1989. Is that right?

Caller: Yeah.


Jill: Okay. Now, for your name, I’ll ask you to say it, then, I may ask you to spell it.

Please, say just your last name.


Caller: Jetson


Jill: Thanks. Now I’ll need your first name. Please say it now.


Caller: George


Jill: Okay. Let me read that back to you to make sure I’ve got it right.
Last name: Jetson, spelled J E T S O N.
First name, George, spelled G E O R G E.
Did I get it right?


Caller: Yes.


Jill: Alright. We’re almost done. Before I send this off, do you have any other last name – for example, a professional or maiden name - that might be listed under this social security number?


Caller: No.


Jill: Okay. I’ve got everything we need. Hold on while I process your request.


I’m sorry, but I wasn’t able to process your request. Let me transfer you to someone who can help you with this. Please hold while I transfer your call.


[Transfer Call]

Chapter 5: Call-Flow Diagrams

5.1Legend for the call-flow diagrams

A high level process indicates a series of play-prompt or interaction states or data retrieval steps, etc.


A play-prompt state plays a waveform, or a series of waveforms, to the caller.


An interaction state prompts the caller for input. It also handles all default timeout and retry behavior. It typically exits (continues to the next state) upon a successful recognition.


The ‘data retrieval’ icon represents back-end transactions, to a database, for example.


The ‘internal decision’ icon represents a logical check in the program code to branch on decision.


Connectors link different call-flow diagrams.


An end-of-call is a transfer, to another service or customer representative, or a system hang-up.



Call-flow diagrams built up of high-level process icons represent the global dialog structure of the application. These high-level diagrams parallel with the more detailed call-flow diagrams that outline every play-prompt, interaction state, data retrieval step, internal decision and possible ends of the call. These low-level charts give a precise graphical representation of the flow of the state tables in the section “Chapter 7: Detailed Dialog Specification”, using the same (or matching) naming convention for easy reference.



5.2High-Level Call Flow Diagram


5.3Outbound Transfer Logic


5.4Name OSDM High-Level Diagram



5.5Name DM Diagram – Default Configuration





5.6Name DM Flow Diagram – Collecting Last Name Only.



Chapter 6: Global Behavior

6.1Time-outs and Retries

While the timeout and retry prompts are specified in the DialogModule tables, they are to be preceded by the appropriate apology prompt as outlined below:


55004

Retry 1&2

IF retry 1

upon rejection of speech

default_noanswerapologies1

I’m sorry, but I didn’t understand you.

55005

upon rejection of dtmf

apology_dtmf1

Sorry, I’m not sure what you entered.

00111

upon confirmation

default_collection_wronganswerapologies1

My mistake.

55006

IF retry 2

upon rejection of speech

default _noanswerapologies2

I’m sorry, but I still didn’t understand you.

51007

upon rejection of dtmf

apology_dtmf2

Sorry, I’m still not sure what you entered.

00113

upon confirmation

default_collection_wronganswerapologies2

My mistake again.

51008

Max Timeout

default_failureprompt

I’m sorry I’m having so much trouble.

51008

Max Retry

default_failureprompt

I’m sorry I’m having so much trouble.

51008

Max Help

default_failureprompt

I’m sorry I’m having so much trouble.

51009

Upon Confirmation Timeout 1

default_confirmation_noinputprompts1

Sorry, I didn’t hear you. Please say YES or NO.

51010

Upon Confirmation Timeout 2

default_confirmation_noinputprompts2

I’m sorry, but I still didn’t hear anything. Please say YES or NO.

50345

Upon Confirmation Retry 1

default_confirmation_reprompts1

Please say YES or NO.

50347

Upon Confirmation Retry 2

default_confirmation_reprompts2

If ‘yes’ press one, otherwise press two.


Typically the timeout and retry prompt specified in the table will be one and the same prompt, but they can also be a set of prompts, and they can also differ between timeout versus retry, or the first versus the second timeout or retry. In exceptional cases, different behavior is specified in the table for the second timeout or retry than outlined above.


Max. timeout is globally set to 2 – exceptions will be indicated in the tables.

Max. retry is globally set to 2 – exceptions will be indicated in the tables.

Max. help is globally set to 2 – exceptions will be indicated in the tables.


  • Upon max timeout (two timeouts):

Play Max Timeout verbiage described above then
Go to: BR3100_AfterHours_Check; NeedAssistanceWith = MaxTimeout

  • Upon max retry (two retries):

Play Max Retry verbiage described above then
Go to: BR3100_AfterHours_Check; set NeedAssistanceWith = MaxRetry

  • Upon max help (two request for help):

Play Max Help verbiage described above then
Go to: BR3100_AfterHours_Check; set NeedAssistanceWith = MaxHelp

  • Upon call completion, hang-up or call transfer, call end processing (call tracking information for reporting) will be performed.


6.2Global Default Settings

Unless otherwise noted, all DMs should use default settings for confidence levels. Exceptions include: 1000_SayLastName, 1020_SayFirstName, 1070_RespellFirst, and 1090_RespellLast.


6.3Privacy

The following information is considered confidential; SSN, Date of Birth, First Name, Last Name, and Other Last Name. The confidential flag should be set to true for all dialog modules collecting this information from the caller.



6.4Help prompts

Start each Help prompt with the Help prompt audio icon (prompt file: icon_help), immediately followed by the Help prompt(s) as specified in the table. Unless otherwise specified by the DialogModule table, the default behavior will always be to ‘re-enter’ the DialogModule directly after the Help prompt has played, so the application will listen for the input again. It does this while resetting any timeout and retry counters, thus as if it were the initial try, but without playing the initial prompt again. This is because the prompt for the input will be contained in the Help prompt itself, perhaps with a slightly different verbiage.

In summary:

1) Start with icon_help, which is the Help audio icon

2) Play Help prompt(s) specified in the UI table

3) Unless otherwise specified in the table, re-enter the same state to listen for caller input

4) Do not play the initial prompt of this state after the Help prompt

Important note: caller can barge-in on the Help prompt (unless otherwise specified by the table) which will cause the Help prompt to immediately stop playing and the recognizer to parse the caller’s input according to the vocabulary of the state following the Help prompt (this state typically is the same state). While the caller can start speaking before the end of the Help prompt, the beginning_of_speech timer will not start until the Help prompt has finished playing (which is the same behavior as with any other prompt played that callers can barge-in on).

6.5Default Confirmation Grammars

Unless otherwise overwritten by local grammars, all Dialog Modules will use the default (standard) confirmation grammars.

6.6Global Commands and Global Prompts

Global Commands Vocabulary

Speech Input

This table specifies the global commands that can be spoken from anywhere in the application. The application behavior upon these commands is always the same, unless the DialogModule specifically overrides the global behavior.


Commands

DTMF

Action (unless re-specified by the module)

Confirm.

Help”

*

First play the Help prompt as specified for the module, then wait for input again. (New prompt for input will be part of each Help message.)

Never

Agent”,
“Operator”,
“Representative”
“Talk to an agent”,
“Talk to an operator”,
“Talk to a representative”

0

Go to: BR3100_AfterHours_Check;

NeedAssistanceWith = UserRequestedAgent


Always


Confirmation prompts

Message Number

Option

Name

Wording

51011

Operator

gl_conf_operator

You said you wanted to talk to one of our operators, Is that right?

Confirmation Option

Vocabulary

DTMF

Action

Confirm.

Yes

Yes [it is]”

[Yes] that’s right”

Right”

[That’s] correct”

1

Go to: BR3100_AfterHours_Check;
NeedAssistanceWith = UserRequestedAgent


Never

No

No [it isn’t]”

[No] that’s not right”

2

Re-enter Dialog Module and play retry 1 or Nomatch 1 prompt as appropriate for the Dialog Module

Never


Developer Notes

On a negative confirmation of the “Agent” global command, return to the Dialog Module where the command was issued and play the retry 1 or nomatch 1 prompt as appropriate for the Dialog Module



6.7DTMF Collection

6.7.1General DTMF Usage

DTMF functionality is available by default through ScanSoft’s OpenSpeech Dialog Modules in collections where numbers are being collected. Although DTMF functionality is native to the Date DialogModule, it has been decided not to advertise its use through the prompting in the application. This will eliminate lengthy or possibly confusing prompts. The underlying DTMF functionality will still reside within the Dialog Module and will be active within the application should a caller enter DTMF digits when prompted for their Date of Birth.

6.7.2Termination of digit strings using the pound sign

Any state prompting for input of which the dtmf equivalent is a digit string, such as the <Get_Social_Security_Number> state, should accept the dtmf ‘pound’ sign as the immediate terminator of such a string. Naturally, this ‘pound’ sign should not be taken as part of the actual input or passed on as such to other parts of the application or any databases; it is merely an indicator that the digits before it form the complete numeric input. For example, while 1-5-0-0-0 indicates $150.00 in states collecting dollar amounts, input of the form 1‑5‑0‑0‑0‑# is a valid indicator as well of that same amount.

Single-digit dtmf equivalents—such as ‘1’, ‘2’, ‘3’, etc. for menu options—do not allow a terminating character.

6.7.3Invalid dtmf input should be rejected

Any input that does not match to a menu option or other command, or does not match to numeric input prompted for at that point, should be rejected by the application, and lead to the application entering a retry. For example, when a state has only four menu options with dtmf equivalents ‘1’ through ‘4’, we should enter a rejection if someone enters ‘5’ at that point. Another example would be a state asking for a sequence of digits: if someone provides dtmf input that contains an asterisk in the sequence, we should reject that input as well. (An alternative would be to go to Help in that situation, since ‘*’ is the dtmf equivalent for it, but it’s probably better to just reject digit-strings containing an ‘*’.) As outlined in the paragraph 6.7.2 above, the dtmf ‘pound’ sign should be accepted as a valid terminator of digit strings.

Please note that dtmf equivalents of global commands should always be accepted, even if they are not explicitly offered by any of the prompts in a given state. Examples of these are the ‘star’ sign for Help and ‘0’ for an Associate.

6.7.4End-of-dtmf timeout

The application’s response time to dtmf input should always be as short as possible, but will depend at any point on whether the dtmf input given so far in a particular state is either clearly unfinished, or is ambiguous.

An example of clearly unfinished dtmf input would be a caller having entered ‘1’ in a state where digit strings of various lengths can be collected, with the shortest input being a single digit. In this situation we give the caller n seconds to enter the remainder of a possible multi-digit string, where n is specified by some inter-digit timeout parameter. After each non-final digit entered by the caller, a countdown will start with a duration indicated by this parameter. If the countdown runs out before the caller has entered the next necessary digit, the application will go into a rejection.

Once the caller has entered the number of digits required to make the input complete—which is 9 digits in the case of an ssn, or 10 digits in case of a US phone number including area code—the application could take that input immediately and parse it, without running the countdown again. However, because the caller may enter the ‘#’ sign to terminate the string, we will look at two variables to determine whether or not we indeed terminate the digit string based upon satisfaction of the number of digits alone:

  1. Fixed-length versus not-fixed-length digit strings. If the expected digit-string is of a fixed length, then we can terminate the string as soon as we have reached the correct number of digits. If its length varies, then we cannot, unless we have reached the maximum allowable length.

  2. Next state being a collection state or not. If the next state in the application is another collection state, and we are not using an inter-digit timeout after the last digit in a fixed-length or maximum-length string, then we run the risk that any ‘#’ terminator entered by the caller will not get detected until the application has moved on to that next collection state. We do not have this risk if the next state is not listening for input, for example a database hit, or a play-message with barge-in turned off. Only where necessary, we eliminate this risk by using the inter-digit timeout even after the last digit of fixed-length or maximum-length string.

In short: we will terminate finished fixed-length and maximum length digit-strings immediately when the next state is not listening for input, and when the next state is a collection state, then for the maximum duration of the inter-digit timeout we will wait for a possible ‘#’ terminator. When a ‘#’ terminator is detected, we also immediately terminate the string.

Unfinished dtmf input can be ambiguous. This is the case when the digit(s) entered so far can be interpreted as complete input for other options or other numeric input. While the input could be considered complete under one interpretation it is incomplete under another interpretation, e.g. someone entered a ‘0’ as the first digit of their Social Security Number, but ‘0’ is also used to request an Associate. In this situation too, we use the inter-digit timeout to wait for possible further input, unless we have reached the maximum length.

6.7.5Key-ahead

In any case, when we know that dtmf input is complete for a given context, the application should respond immediately and not run an end-of-dtmf-input countdown. If we were to introduce such a delay after each complete dtmf input, then we would seriously hinder the ability of power-users to comfortably ‘key-ahead’ through menus.

The so-called ‘key-ahead’ feature automatically works because of the zero-length timeout upon unambiguous dtmf input. As soon as the caller hits one of the numbers on the keypad to choose a menu option, the application takes that digit and moves to the next state accordingly. If that response to the dtmf input takes a fraction of a second and the next state is a collection state again, then this next state will automatically take the next digit if it is a voice menu or the next sequence of digits if it is expecting a digit string. If the next state was a database hit instead, for example, then no input will be accepted during the database hit (because the app is not listening for anything), and once the application returns to a collection state, further input is listened for from then on. This means that if that database hit happened to have sub-zero response time, the user could have run right over it using 'key-ahead' and never noticed anything. No key-ahead is possible over database hits that need more time, or over play-states that have barge-in turned off. Naturally, over states expecting variable-length digit-string input, 'key-ahead' can only be achieved by using the ‘#’ terminator.

6.8Digit-String Playback

Variable digit-strings to be presented to the caller will be passed through a global routine that builds prompt lists to fluently play back Social Security Numbers. Valid input to this function is a string of digits, where a hyphens and spaces can be used to indicate grouping. For example: “017-85-3229”. For each hyphen or space, the routine will insert a pause. The prompt set to be used for this consists of the following 1,231 prompts:

1,000 prompts: “...0 0 0, ...” through “...9 9 9, ...” (Non-final intonation)

100 prompts: “...0 0, ...” through “...9 9, ...” (Non-final intonation)

100 prompts: “...0 0.” through “...9 9.” (Final intonation)

10 prompts: “0...” through “9...” (Rising intonation)

10 prompts: “...0, ...” through “...9, ...” (Non-final intonation)

10 prompts: “...0.” through “...9.” (Final intonation)

1 prompt: 1/4 second silence.


6.9Event Logging

Throughout all the User Interface Specifications, each state calls out the event logging that is unique to that state. For an overview of all of Event Logging, including global behavior for events such as what to do if an info token is not available; see the Event Logging section in the Functional Requirements Specification document.

6.10Internal DialogModule Functionality




Chapter 7: Detailed Dialog Specification

7.1How to Read the Call-Flow Tables

Speech Input

Play Prompt

Database Query

Branch on Condition


2100_Finance_Forex_Menu

Speech Input

Item List


Entering from

2000_Finance_Menu


Prompts

Type

Name

Wording

Initial

21001

For which currency would you like to hear the exchange rate?

Timeout 1

21002

I’m sorry, I didn’t hear you. Please say the currency you want an exchange rate for, for example “Sterling Pound”.

Timeout 2

21003

I’m sorry, I still didn’t hear you. Please say the currency you want to hear the exchange rate for, such as the “Japanese yen”, or, to hear a full list to choose from, say “List all currencies”.

Retry 1

21004

Please say the currency you want an exchange rate for, for example “Australian dollar”.

Retry 2

21005

Please say the currency you want to hear the exchange rate for, such as the “Japanese yen”, or, to hear a full list to choose from, say “Dutch guilder”.

Help

21006

You are in the foreign exchange menu. If you specify a currency, such as the “Danish krone”, I’ll give you the exchange rate for it against the US Dollar.


Voicing

DTMF

Action

<currency>


Go to: "2110_Finance_Forex_ExchangeRateInfoMsg"

List all currencies”,
“List currencies”, “List all”,
“List them all”, “List them”

2

Go to: "2190_Finance_Forex_CurrenciesListIntro"


Commands

DTMF

Action

Back up”

#

Go to: “2000_Finance_Menu”

Main menu”

##

Go to: “1000_MainMenu”

Goodbye”

*

Go to: “9000_Goodbye_Msg”

Instructions”

9

Play prompt help prompt and then re-enter this module, playing the initial prompt, awaiting new user input.

Operator”

0

Go to: "8000_Transfer_Msg"


Developer notes

Default


7.2Call-Flow Tables

DB0000_Ping_System

Database Query

Ping system upon entry to ensure the presence of the back end


Entering from

N8NN Main Menu


Condition

Action


Go to: BR1000_System_And_Operator_Availability


Event logging

AltNameCollected = False; NeedAssistanceWith = NULL

BR1000_System_And_Operator_Availability

Branch on Condition

Branch of availability of system and operators.


Entering from

DB0000_Ping_System


Condition

Action

IF System is unavailable


Go to: BR3100_AfterHours_Check

NeedAssistanceWith = SysUnavailable

Else


Go to:BR1900 Check Null Condition


Event logging



PP1500_Getting_Help_Operator

Play Prompt

Call needs assistance from live operator


Entering from

BR3100_AfterHours_Check


Prompts

Message Numbers

Condition

Name

Wording

15005

NeedAssistanceWith = BadAOR

15001

Alright. To make sure we have your most recent address on file, I’ll connect you with an agent. They’ll be able to help you with this.

15006

NeedAssistanceWith = ValidationFailure


15002

I’m sorry, but I wasn’t able to process your request. Let me connect you to someone who can help you with this. Please hold while I transfer your call.

15007

NeedAssistanceWith = AccountBlocked

15003

Our records show that you requested that your account be blocked from access by this automated system, as well as by the Internet, even with a password, so I’ll need to send you to an agent to complete this transaction. If you want to unblock your account, the agent must handle that as well. Hold on while I connect you to someone who can help you with this.

15008

NeedAssistanceWith = SysUnavailable

15004

I’m sorry, but the system is unavailable at this time. Please hold while I transfer your call to someone who can help you.

15009

NeedAssistanceWith = MaxNameRecognitionFailures

15005

Let me connect you with someone who can help you. Please hold while I transfer your call.

15010

NeedAssistanceWith = MaxTimeout

15006

<default> Let me connect you to an agent who can help you. Please hold while I transfer your call.

15011

NeedAssistanceWith = MaxRetry

15007

<default> Let me connect you to an agent who can help. Please hold while I transfer your call.

15012

NeedAssistanceWith = MaxHelp

15009

You know what? Let me connect you to an agent who can help. Please hold while I transfer your call.

15013

NeedAssistanceWith = UserRequestedAgent

15008

Sure. One moment. I’ll transfer you to someone who can help.


Condition

Action

Always

Go to: [TRXF TO AGENT]


Event logging



Developer notes

No barge-in



BR1900 Check Null Condition




Entering from

BR1000_System_And_Operator_Availability



Condition

Action

If TVDC Items to collect= 0

Go to: BR3999 Social Security Check Condition

If TVDC items else

Go to: P2000_Standard_Greeting



P2000_Standard_Greeting

Play Prompt

Standard Greeting


Entering from

BR1900 Check Null Condition


Prompts

Message Number

Condition

Name

Wording

20004

Entering from SpeakFreely N8NN AND Task=BEVE

20004

I’d be happy to help you get a Benefits Verification letter. To do that, I’ll need to ask you up to five questions.

20005

Entering from SpeakFreely N8NN AND Task=MRC

20005

I’d be happy to help you get a replacement Medicare card. To do that, I’ll need to ask you up to five questions.


Condition

Action

Always

Go to: BR2988-Attestation Flag Check


Event logging



Developer notes

No barge-in

BR2988-Attestation Flag Check





Entering from

P2000_Standard_Greeting



Condition

Action

If Attestation Flag = 0

Go to: DM2990_AttestationYN

If Attestation Flag = else

Go to: DM3000_Check_AOR



DM2990_AttestationYN

YesNo

OMB Attestation


Entering from

BR2988-Attestation Flag Check


Prompts

Message Number

Type

Name

Wording

Barge-in

29901

Initial-1

29901

Social Security is allowed to collect this information under the Social Security Act. This information collection meets the requirements of the Paperwork Reduction Act under O.M.B. number zero, nine, six, zero, zero, five, nine, six. We estimate that it will take about 10 minutes to listen to the instructions, gather the facts, and answer the questions.



Please note that any person who makes a false representation in an effort to alter or obtain information from the Social Security Administration may be punished by a fine or imprisonment, or both.


NO

29902

Initial-2

29902

Do you understand and agree to these terms?

Yes

29903

Retry1

29903

[ Global Default] Do you understand and agree to these terms? Please say YES or NO.

Yes

29904

Retry2

29904

[ Global Default] Any person who makes a false representation in an effort to alter or obtain information from the Social Security Administration may be punished by a fine or imprisonment, or both.  If you understand and agree to these terms, press one. Otherwise press two

Yes

29905

Timeout1

29905

Sorry, I didn’t hear anything. Do you understand and agree to these terms? Please say YES or NO.

Yes

29906

Timeout2

29906

I’m sorry, but I still didn’t hear anything. Any person who makes a false representation in an effort to alter or obtain information from the Social Security Administration may be punished by a fine or imprisonment, or both. Do you understand and agree with these terms? You can say YES or press 1; or NO or press 2.

Yes

29907

Help

29907

Before we can continue, I need to know that you understand and agree with the following warning. Any person who makes a false representation in an effort to alter or obtain information from the Social Security Administration may be punished by a fine or imprisonment, or both. Do you understand and agree to these terms? You can say YES or press 1, or NO or press 2.

Yes

00120

Success-1

(Caller says Yes)

00120


Alright.

N/A

12101

Success-2

(Caller says No or max retry/timeout or Max Help)

12101


Thank you for calling Social Security. Goodbye.

N/A


Confirmation Option

Vocabulary

DTMF

Action

Confirm.

Yes

Yes and usual synonyms (including “[Yes] I do”)

1

Play Success-1

Set Attestation Flag to 1

Go to: DM3000_Check_AOR

Never

No

No and usual synonyms

2

Play Success-2

And then hang up

Never


Reporting



Record = U-



RECL



-DM_2990-(Call Duration at start),T-RECL-

0000 = Success



-Call duration at process end

0001 = Error

0002 = Max No Input

0003 = Max No Match

0200 = Caller Hang Up


Developer notes


DM3000_Check_AOR

YesNo

Check if the caller’s address of record is correct


Entering from

BR2988-Attestation Flag Check,DM2990_AttestationYN


Prompts

Message Numbers

Type

Name

Wording

30020

Initial

300010

To get started, I want to make sure I’ll be sending it to the right place. Have you been at the same mailing address for at least a month?

30021

Retry 1

300020

< default global .> For the past 30 days, have you been at the same mailing address? Please say “YES” or “NO”.

30022

Retry 2

300030

< default global > If you have been at the same mailing address for at least a month press one. Otherwise, press two

30023

Timeout 1

300040

I’m sorry but I didn’t hear you and I want to make sure you’ll receive the mail I send. Have you been at the same mailing address for at least a month? Please say “YES” or “NO”.

30024

Timeout 2

300050

I’m sorry but I still didn’t hear you. Please answer “YES” or “NO”. For the past 30 days, have you been at the same mailing address?

30025

Help

300060

Sure. If you’ve moved recently or your mailing address has changed, it may not be up to date in our records. Have you been at the same mailing address for at least a month? Please answer “YES” or “NO”. If you’re unsure what to answer, say “Agent” and I’ll connect you with someone who can help.


Option

Vocabulary

DTMF

Action

Confirm.

Yes

Yes ”

[Yes] I have”


1

Go to: BR3999 Social Security Check Condition


Never

No

No [I haven’t]”

No [I have not]”


2

NeedAssistanceWith = BadAOR

Go to: DB3050_Check_AOR_Ping

Never


DialogModule parameters

Parameter

Value

after_end_of_speech_timeout

500 ms

before_begin_of_speech_timeout

7,000 ms

allowing_barge_in

True


Event logging



Developer notes

There are no special developer notes for this DM

DB3050_Check_AOR_Ping

Database Query

Message to host for MI = 13 is to be used if caller enters this state.


Entering from

DM3000_Check_AOR


Condition

Action


Go to: BR3100_AfterHours_Check


Event logging



BR3100_AfterHours_Check

Branch on Condition

Branches on whether operators are standing by.


Entering from

DB3050_Check_AOR_Ping BR8000_DB_Request_Validate_1st


Condition

Action

If During Hours

Go to: PP1500_Getting_Help_Operator

IF After Hours

Go to: DM11000_ReturnToMain_or_HangUP


Event logging

Pass NeedAssistanceWith value onto next state



BR3999 Social Security Check Condition




Entering from

DM3000_Check_AOR, BR1900 Check Null Condition



Condition

Action

If SSN = null

Go to: 4000_Get_SS_Number

If SSN else

Report V Transactions per module note, Go to: BR4005 Get DoB Check Condition

Module Notes

V-MEDI-SSN_1-(duration),T-MEDI-0000-(duration)


4000_Get_SS_Number

Social Security DialogModule™

Get the callers Social Security Number


Entering from

BR3999 Social Security Check Condition


Prompts

Message Number

Type

Name

Wording

54201

Initial

400010

Please say your Social Security number like this: 1 2 3 – 4 5 – 6 7 8 9, or enter it on your keypad.

54202

Retry 1

400020

[Global Default] Please say your nine digit social security number quickly like this: 1 2 3 – 4 5 – 6 7 8 9, or enter it on your keypad.

50203

Retry 2

400030

< default global > Try entering it on the telephone keypad.

50204

Timeout 1

400040

Sorry. I didn’t hear anything. Please enter or say your nine digit social security number now.

50205

Timeout 2

400050

I’m sorry, but I still didn’t hear anything. Try saying your social security number one digit at a time. It works best if you speak at a normal pace. For example: 1 2 3 – 4 5 – 6 7 8 9.

50206

Help

400060

You can tell me your nine digit social security number by simply saying it one digit at a time. For example: 1 2 3 – 4 5 – 6 7 8 9. It works best if you don’t use double digit numbers like sixty-seven or eighty-nine. Please try it again now.


Option

Vocabulary

DTMF

Action

Confirm.

SSN

<SSN>

<SSN>


Always


Confirmation prompts

Message Number

Option

Name

Wording

Result

50207

SSN

400070

This is important, so I want to make sure I have it right. Your social security number is:


50208


400070b

Okay now I think I’ve got it right. Your social security number is:




<SS_Num>

CPR

1 2 3 – 4 5 – 6 7 8 9

50209


400071

Is that right?

This is important, so I want to make sure I have it right. Your social security number is: 1 2 3 – 4 5 – 6 7 8 9. Is that right?

40015

Retry 1

400080

Sorry. I didn’t catch that. Please say “YES” if I have the right number.

Sorry. I didn’t catch that. Please say “YES” if I have the right number. 1 2 3 – 4 5 – 6 7 8 9. Is that right?

40016

Timeout 1

400090

I wasn’t sure if you said anything. Please say “YES” if I have the right number.

I wasn’t sure if you said anything. Please say “YES” if I have the right number. 1 2 3 – 4 5 – 6 7 8 9. Is that right?


Confirmation Option

Vocabulary

DTMF

Action

Confirm.

Yes

Yes [it is]”

[Yes] that’s right”

Right”

[That’s] correct”

1

Go to:BR4005 Get DoB Check Condition


Never

No

No [it isn’t]”

[No] that’s not right”

2

Re-enter Dialog Module per default behavior

Never

DialogModule parameters

Parameter

Value

after_end_of_speech_timeout

2,000 ms

before_begin_of_speech_timeout

7,000 ms

allowing_barge_in

True


Event logging

Fill semantic item <SS_Num>


DialogModule Notes

        Area, group or serial number containing only zeros are invalid

        Area numbers greater than or equal to 800 are invalid

        “Dashes” and “hyphens” should be ignored when uttered by the caller, but these utterances may be discarded by the recognizer itself

     DTMF and speech expect 9 digits. It may be possible to speak more than 9 digits, but only nine digits will be recognized

Note: Point to non-standard grammar that includes Natural Numbers

Set Confidential Flag to TRUE


BR4005 DOB Check Condition




Entering from

DM4000_Get_SS_Number, BR3999 Social Security Check Condition



Condition

Action

If DOB = null

Go to: 5000_Get_DOB

If DOB else

Report V Transactions per module note, 400- Name Check Condition

Module Notes

V-MEDI-DOB_1-(duration),T-MEDI-0000-(duration)


5000_Get_DOB

Date DialogModule™

Get the callers Date Of Birth


Entering from

BR4005 DOB Check Condition


Prompts

Message Number

Type

Name

Wording

50010

Initial

500010

And what’s your date of birth? [big pause] For example, you can say…May 5th, 1957.

50011

Retry 1

500020

< default global .> Please tell me your birth date again. It works best if you speak at a normal pace.

50012

Retry 2

500030

< default global > Try saying the month followed by the date and the year you were born. For example July 4th, 1976.

50013

Timeout 1

500040

Sorry, I didn’t hear you. Tell me your birth date again.

50014

Timeout 2

500050

I’m sorry, but I’m still having trouble hearing. I need the month, day and year for your birthday. You know like…July 4th, 1976.

50015

Help

500060

Aside from your social security number, I’ll need your date of birth. You can say this in a number of ways. For example you can say “July 4th 1976”, or “the fourth of July, 1976” Go ahead. What’s your date of birth?


Option

Vocabulary

DTMF

Action

Confirm.

Date

<date>

<...>


Always


Confirmation prompts

Message Number

Option

Name

Wording

Result

50016

Date

500070

Okay, so that’s::




<Date>

CPR

January 12th 1931

50017


500071

Is that right?

Okay, so that’s: <January 12th, 1931>. Is that right?

50018

Retry 1

500080

Sorry. I didn’t catch that. Please say “YES” if I have the right date.

Sorry. I didn’t catch that. Please say “YES” if I have the right date. <January 12th, 1931>. Is that right?

50019

Timeout 1

500090

I wasn’t sure if you said anything. Please say “YES” if I have the right date.

I wasn’t sure if you said anything. Please say “YES” if I have the right date. <January 12th, 1931>. Is that right?


Confirmation Option

Vocabulary

DTMF

Action

Confirm.

Yes

Yes [it is]”

[Yes] that’s right”

Right”

[That’s] correct”

1

Go to: 400- Name Check Condition

names_to_collect = LAST_FIRST

Never

No

No [it isn’t]”

[No] that’s not right”

2

Re-enter Dialog Module per default behavior

Never

DialogModule parameters

Parameter

Value

date_reference_date

System date [yyyymmdd]

date_range_allowed_earliest

19000101

date_range_allowed_latest

Today [yyyymmdd]

date_range_expected_earliest

Today – 75 years [yyyymmdd]

date_range_expected_latest

Today – 25 year [yyyymmdd]

date_disambiguation_mode

ASSUME_NOTHING

after_end_of_speech_timeout

1,250 ms

before_begin_of_speech_timeout

7,000 ms

allowing_barge_in

True


Event logging

Fill semantic item <Date_Of_Birth>


DialogModule Notes

  • Although the application does not explicitly guide callers to use DTMF for the Date of Birth entry, it is enabled.

  • Date entry should be in the form of MM/DD/YYYY to be accepted.

  • Trim the grammar so that the day of the week is not allowed

Set Confidential Flag to TRUE



400- Name Check Condition




Entering from

BR4005 Get DoB Check Condition. 5000_Get_DOB



Condition

Action

If First Name, Last Name = null

Set names to collect to Last_First; Go to: 500_EntryPrompt

If First Name = else Last Name = null

Report V Transactions per module note, Set names to collect to Last; Go to: 1000-EntryPrompt-Msg

If First Name = null and Last Name = else

Report V Transactions per module note, Set names to collect to First, Go to:1020_SayFirstName

If First Name, Last Name = else

Report V Transactions per module note, Go to: BR5500_Alt_Name_Collected

Module Notes

First: V-MEDI-FN_1-(duration),T-MEDI-0000-(duration)

Last: V-MEDI–LN_1-(duration),T-MEDI-0000-(duration)


500_EntryPrompt

Play Prompt

Explain name collection ground rules to user


Entering from

400- Name Check Condition


Prompts

Message Number

Name

Wording

50301

default_name_entryprompt

Now I need your full name. Let's start with your LAST name.


Condition

Action

If “ names_to_collect” = FIRST or FIRST_LAST




If spelling_only = TRUE

Go to: 1030_SpellFirstNameplaying initialprompt2

Else

Go to: 1020_SayFirstNameplaying initialprompt1

If “names_to_collect” = LAST or LAST_FIRST

If spelling_only = TRUE

Go to:1010_SpellLastName playing initialprompt2

Else

Go to:1000_SayLastName playing initialprompt1


Module Settings

No barge-in

Note: This is the parameter entry prompt and can be user-specified.

Developer notes

This state shares prompting with KBA 1000_EntryPrompt

1000_SayLastName

CustomContext

Get the user’s last name.


Entering from

500_EntryPrompt; DM9000_Check_For_Alt_Name, 400- Name Check Condition


Prompts

Message Number

Type

Condition

Name

Wording

50304

Initial 1

If from 500_EntryPrompt

default_name_saylast_collection_initialprompt


For now I just need your last name – I’ll get your first name later. Please SAY and then SPELL JUST your last name. For example, if your last name was Kusack, you’d say Kusack, K U S A C K. Go ahead.

50305

Initial 2

If from DM9000

default_name_sayandspelllast_collection_initialprompt3

Please say your OTHER LAST name including the spelling. [Short Pause] For example if it was Jones, you’d say “Jones, J O N E S”. Go ahead.

50307

Timeout 1

default_name_saylast_collection_noinputprompts1

Sorry, I didn’t hear you. Please give me the last name with the spelling.

50308

Timeout 2

default_name_saylast_collection_noinputprompts2

I’m afraid I still can’t hear you. Please give me the last name and spell it.

50309

Retry 1

If originally from 500_EntryPrompt

default_name_saylast_collection_nomatchprompts1

<default global> . Please say JUST your last name including the spelling.

50310

Retry 1

If originally from DM9000

default_name_saylast_collection_nomatchprompts2

<default global> Please SPELL your other last name for me, like this: “S M I T H”...

50312

Help

default_name_saylast_collection_helpprompts1

I need you to say the last name and then spell it for me. For example, if the last name was O’Neal, you’d say “O’Neal O N E A L”.


Condition

Sub condition

DTMF

Action

Confirm.

Confidence>=high confidence level

(High Confidence)

IF names_to_collect =

LAST_FIRST


Go to: "1020_SayFirstName"

Never

ELSE (we’re done, see note below)


Go to: "1040_ConfirmName"


Confidence<high confidence level

(Low and Medium Confidence)



Go to: "1010_SpellLastName"


Failure and Last Name



Go to: "3000_ExitFailurePrompt


Failure and Alt Name



Go to: “PP6000_Ready_To_Submit




Module Settings

Note: High confidence Accept, Medium and Low Confidence Spell. In the case of low confidence, we ask spelling directly rather than reprompt. Therefore, Nomatch 1 is only played when a caller utters a global command and then negatively confirms a global command.

Note: Test always_ask_spelling parameter. If true, Go to: 1010_SpellLastNameregardless of confidence score.

Note: Test overallconfirmation parameter. If overallconfirmation = NEVER , Go to 4000_ExitSuccessPromptsinstead of going to 1040_Confirmname.

Note: High Confidence should be set to .875

Deactivate global “AGENT” and “HELP” grammar in this DM. This will remove all agent vocabulary items described in section 6.6 from this collection (e.g. “agent”, “representative”, “operator”, etc.)

Developer notes

Set Confidential Flag to TRUE


1010_SpellLastName

CustomContext

Ask user to spell their last name.


Entering from

1000_SayLastName, 500_EntryPrompt


Prompts

Message Number

Type

Name

Wording

50314

Initial 1

(On entry from 1000_SayLastName) spellingonly = FALSE.

default_name_spelllast_collection_initialprompt1

Now please JUST spell that for me, and spell it quickly.

10019

Initial 2

(On entry from 500_EntryPrompt) spellingonly = TRUE.

default_name_spelllast_collection_initialprompt2

Please spell your last name, one letter at a time.

10020

Spellingonly=TRUE & namestocollect = FIRST_LAST

default_name_spelllast_collection_initialprompt3

Now, spell your “last” name.

50315

Timeout 1

default_name_spelllast_collection_noinputprompts1

Sorry I didn’t hear you. Using only the letters of the alphabet, please spell your last name quickly, one letter at a time.

50318

Timeout 2

default_name_spelllast_collection_noinputprompts2

I’m afraid I still can’t hear you. It works best if you use ONLY letters and speak at a quick pace. For example, to spell ‘Smith, you don’t need to say S as in Sam, M as in Michael, just say S M I T H.…try it again.

50319

Retry 1

default_name_spelllast_collection_reprompts1

< default global > Using only the letters of the alphabet, please spell your last name quickly. For example, if your name was O’Connor, you would say O C O N N O R. Please spell the last name now.

50322

Retry 2

default_name_spelllast_collection_reprompts2

< default global > If the last name has an apostrophe, space or a hyphen in it, you can just skip that. For example, if it's a two part name like Folsom hyphen Jones, you should just drop the hyphen and not worry about capital letters. Just say f-o-l-s-o-m-j-o-n-e-s. Try spelling the last name one more time.

50323

Help

default_name_spelllast_collection_helpprompts1

I need you to spell just the last name. If the last name has an apostrophe, space or a hyphen in it, you can just skip that. It works best if you use ONLY letters and speak at a quick pace. For example, to spell Smith, you don’t need to say S as in Sam, M as in Michael, just say S M I T H … try it again. Please spell the last name for me now.


Condition

Action

Confirm.

If names_to_collect = LAST_FIRST

Go to: 1020_SayFirstName

Never

ELSE

Go to: 1040_ConfirmName


failure

Go to: 3000_ExitFailurePrompt




Module Settings

Play success prompt.

Developer notes

Set Confidential Flag to TRUE


1020_SayFirstName

CustomContext

Get the user’s first name.


Entering from

500_EntryPrompt,1000_SayLastName ,1010_SpellLastName, 400- Name Check Condition


Prompts

Message Number

Type

Name

Wording

50324

Initial

default_name_sayfirst_collection_initialprompt

Now say and spell your FIRST name. [Short Pause] For example if your first name was Robin, you’d say “Robin, R O B I N”. Go ahead.

50325

Timeout 1

default_name_sayfirst_collection_noinputprompts1

Sorry, I didn’t hear you. Please give me your first name with the spelling.

50326

Timeou 2

default_name_sayfirst_collection_noinputprompts2

I’m afraid I still can’t hear you. Please give me your first name and spell it.

50327

Retry 1

default_name_sayfirst_collection_nomatchprompts1

<default global> Please give me your first name including the spelling.

50328

Help

default_name_sayfirst_collection_helpprompts1

I need you to say your first name and then spell it for me. For example if your first name was Nick, you’d say “Nick, N I C K”.


Condition

Sub Condition

Action

Confirm.

Confidence>=high confidence level

(High Confidence)

IF names_to_collect =FIRST_LAST

Go to: “1000_SayLastName

Never

Else (see note below)

Go to: "1040_ConfirmName"


Confidence<high confidence level

(Low and Medium Confidence)


Go to: "1030_SpellFirstName"


failure


Go to: "3000_ExitFailurePrompt

If necessary



Module Settings

Note: High confidence Accept, Medium and Low Confidence Spell. In the case of low confidence, we ask spelling directly rather than reprompt. Therefore, Nomatch 1 is only played when a caller utters a global command and then negatively confirms a global command.

Note: Test “alwaysaskspelling” parameter. If true, Go to: 1030_SpellFirstNameregardless of confidence score.

Note: Test overallconfirmation parameter. If overallconfirmation = NEVER, Go to 4000_ExitSuccessPromptsinstead of going to 1040_Confirmname.

Note: High Confidence should be set to .85

Deactivate global “AGENT” and “HELP” grammar in this DM. This will remove all agent vocabulary items described in section 6.6 from this collection (e.g. “agent”, “representative”, “operator”, etc.)

Developer notes

Set Confidential Flag to TRUE


1030_SpellFirstName

CustomContext

Ask user to spell first name.


Entering from

1020_SayFirstName, 500_EntryPrompt


Prompts

Message Number

Type

Name

Wording

50329

Initial 1

(on entry from 1020_SayFirstName) spellingonly = FALSE

default_name_spellfirst_collection_initialprompt1

Now, please SPELL your first name for me quickly using just the letters in the alphabet.

10032

Initial 2

(On entry from 500_EntryPrompt) spellingonly = TRUE.

default_name_spellfirst_collection_initialprompt2

Please spell your first name, one letter at a time.

10033

Initial 3

Spellingonly=TRUE & namestocollect = LAST_FIRST

default_name_spellfirst_collection_initialprompt3

Now, spell your “first” name.

50330

Timeout 1

default_name_spellfirst_collection_noinputprompts1

Sorry I didn’t hear you. Please spell your first name one letter at a time.

50331

Timeout 2


default_name_spellfirst_collection_noinputprompts2

I’m afraid I still can’t hear you. Using only the letters of the alphabet, please spell your first name now.

50332

Retry 1

default_name_spellfirst_collection_reprompts1

Saying just the letters of the alphabet, please spell your first name. For example, if your name were Robin, instead of saying R as in Radar, O as in Oscar, you could just say R O B I N. Go ahead. Spell your first name now.

50333

Retry 2

default_name_spellfirst_collection_reprompts2

< default global > Please spell your first name one more time. And remember, please use ONLY the letters of the alphabet and speak quickly. Go ahead.

50334


Help

default_name_spellfirst_collection_helpprompts1

I need you to spell just your first name. If your first name has an apostrophe or a hyphen in it, you can just skip that. Now, go ahead and spell your first name.


Condition

Action

Confirm.

names_to_collect = FIRST_LAST

Go to: "1000_SayLastName

Never

Else

Go to: 1040_ConfirmName


failure

Go to: DM3000_Check_AOR




Module Settings

Default: Play success prompt.

Developer notes

Set Confidential Flag to TRUE

1040_ConfirmName

YesNo

Confirm name collection


Entering from

1000_SayLastName, 1010_SpellLastName, 1020_SayFirstName, 1030_SpellFirstName

Pre-Conditions

If name to collect = First

Start at msg. # 50336, default_name_lastname

If name to collect = Last

Start at msg. # 50339, default_name_firstname

If name to collect = First and Last

Start at msg. # 50336, default_name_lastname

Prompts

Message Number

Type

Name

Wording

50335


Initial on entry

Okay. Let me read that back to you to make sure I’ve got it right.

50336

Play this series of prompts if we need to play out the last name

default_name_lastname

Last name:



<lastname> or use TTS

50337

default_name_spelled

Spelled:

00250


250 ms silence



<Letter (1 )>…

00250


250 ms silence



...<Letter (2)…

00250


250 ms silence



...<Letter (N)

00250


250 ms silence

50338

If no audio is available for the last name, play this prompt instead

default_name_lastnamespelled

Last name spelled…

50339

Play this series of prompts if we need to play out the first name

default_name_firstname

First name:




<firstname> or use TTS

50340


default_name_spelled

Spelled:

00250



250 ms silence




<Letter (1 )>…

00250



250 ms silence




...<Letter (2)…

00250



250 ms silence




...<Letter (N)

00250



250 ms silence

50341

If no audio is available for the first name, play this prompt instead

default_name_firstnamespelled

First name spelled…

50342


default_confirmation_initialprompt_part2

Did I get that right?

50343

Timeout 1

default_confirmation_noinputprompts1

Sorry I didn’t hear you. Did I get the name right? Please say yes or no.

50344

Timeout 2

default_name_confirmname_collection_noinputprompts2

I’m afraid I still can’t hear you. Did I understand your name correctly?

50345

Retry 1

default_name_confirmname_collection_reprompts1

< default global > Please say “yes” or “no”.

50347

Retry 2


default_confirmation_reprompts2

< default global > If ‘yes’ press one, otherwise press two.

50346

Help

default_name_confirmname_collection_helpprompts1

If I got it right, just say “yes”, otherwise if I made a mistake, say “no”. Now, did I get it right?


Option

Vocabulary

DTMF

Action

Confirm.

Yes

Yes [you did]”

You did”

[Yes] [that’s] right”

[That’s] correct”

okay”

1

Go to: 4000_ExitSuccessPrompts

Never

No

No [you didn’t]”

[No] that’s wrong”

[No] that’s not right”

wrong”

no you did not”

2

Go to: 1050_ConfirmationApology

Never

failure



Go to: 3000_ExitFailurePrompt



Module Settings

Note: Play the series of prompts in the order specified by the parameter “namestocollect”.

Note Also: The failure prompt for this state is only played in the case where the DM exited due to maxnoinputs or maxnomatches.

Suppress YesNo success prompts.

Developer notes


1050_ConfirmationApology

Play Prompt

User rejected name, apologize, and set up a second try.


Entering from

1040_ConfirmName


Prompts

Message Number

Condition

Name

Wording

50348

Always

default_name_confirmationapology

Sorry about that. Let’s try again.


Condition

Action

If names_to_collect = LAST

Go to: 1090_RespellLast

If names_to_collect = FIRST

Go to: 1070_RespellFirst

If names_to_collect = LAST_FIRST

or FIRST_LAST

Go to: 1060_GetMistake


Module Settings

No barge-in

Developer notes


1060_GetMistake

CustomContext

Isolate the mistake. First Last or Both


Entering from

1050_ConfirmationApology


Prompts

Message Number

Type

Name

Wording

50349

Initial

default_name_getmistake_collection_initialprompt

Which part is wrong? The first name, the last name, or both names?


50350

Timeout 1

default_name_getmistake_collection_noinputprompts1

Sorry I didn’t hear you. Which part of the name did I get wrong? “The first name”, “the last name”, or “both names”?

50360

Timeout 2


default_name_getmistake_collection_noinputprompts2

I’m afraid I still can’t hear you. Please tell me what I got wrong: “the first name”, “the last name”, or “both names”.

50361

Retry 1

default_name_getmistake_collection_reprompts1

<default global> I know I don’t have the name right just yet. Please tell me which part is wrong: “the first name”, “the last name”, or “both names”.

50362

Retry 2

default_name_getmistake_collection_reprompts2

<default global> Which part of the name do I need to fix? Please say ‘the first name”, “the last name”, or “both.

50363

Help

default_name_getmistake_collection_helpprompts1

I need to know which name I got wrong to correct it. Just say the part of the name that I didn’t catch: “the first name”, “the last name”, or “both names”.


Maxnomatch


N/A Play failure prompt and Go to: 3000_ExitFailurePrompt


Option

Vocabulary

Action

Confirm.

firstname”

[the]first name

Go to:1070_RespellFirst


lastname”

[the]last name

Go to: 1090_RespellLast


both”

Both [of them | names]

the first [name] and the last [name]

If “names_to_collect” = FIRST_LAST

G to: 1090_RespellLast


If “names_to collect” = LAST_FIRST

Go to: 1090_RespellLast

failure


Go to: 3000_ExitFailurePrompt




Module Settings


Developer notes


1070_RespellFirst

CustomContext

Ask for a respelling of first.


Entering from

1050_ConfirmationApology,1060_GetMistake, 1090_RespellLast


Prompts

Message Number

Type

Name

Wording

50367

Initial (if we needed to spell the first name previously

default_name_respellfirst_collection_initialprompt1

Saying just the letters of the alphabet, please spell your first name again.

50369

Timeout 1

default_name_spellfirst_collection_noinputprompts1

Sorry I didn’t hear you. Please spell your first name one letter at a time.

50370

Timeout 2

default_name_spellfirst_collection_noinputprompts2

I’m afraid I still can’t hear you. Please spell your first name now.

50371

Retry 1

default_name_spellfirst_collection_reprompts1

< default global > Saying just the letters of the alphabet, please spell your first name. For example, if your name were Robin, instead of saying R as in Radar, O as in Oscar, just say R O B I N. Go ahead. Spell your first name now.

50372

Retry 2


default_name_spellfirst_collection_reprompts2

< default global > Please spell your first name one more time.

50373

Help

default_name_spellfirst_collection_helpprompts1

I need you to spell just your first name. If your first name has an apostrophe or a hyphen in it, you can just skip that. Now, go ahead and spell your first name.

Option

Vocabulary

DTMF

Confirm.

<FirstName>

<alpha input>

N/A

Always

Confirmation Prompts

Message Number

Option

Name

Wording

Result

50374

Confirm

default_name_confirmation_initialprompt_part1

Okay. I think I’ve got it right now.

Okay. I think I’ve got it right now. First name spelled <…>, Did I get that right?

50341

default_name_firstnamespelled

First name spelled:

50342

default_confirmation_initialprompt_part2

Did I get that right?

00118

command

default_confirmation_initialprompt_part1

I think you said…

I think you said <…> Did I get that right?

50342

default_confirmation_initialprompt_part2

Did I get that right?


Confirmation Options

Vocabulary

DTMF

Action

Confirm.

Yes”

Yes [it is]”

[Yes] that’s right”

Right”

[That’s] correct”

1

Go to: 4000_ExitSuccessPrompts

Never

No”

No [it isn’t]”

[No] that’s not right”

2

Re-enter Dialog Module per default behavior

Never

MaxFailure


N/A

Go to:3000_ExitFailurePrompt



Module Settings

Note: Confidence Level should be set to .72

Developer notes

Set Confidential Flag to TRUE

Set confidence levels to .400

1090_RespellLast

CustomContext

Get the user’s first name.


Entering from

1050_ConfirmationApology, 1060_GetMistake


Prompts

Message Number

Type


Wording

50379

Initial (if we needed to spell the last name previously

default_name_respelllast_collection_initialprompt1

Saying just the letters of the alphabet, please spell your last name again.

50385

Timeout 1

default_name_spelllast_collection_noinputprompts1

Sorry I didn’t hear you. Please spell the last name one letter at a time.

50386

Timeout 2

default_name_spelllast_collection_noinputprompts2

I’m afraid I still can’t hear you. It works best if you use only letters and speak at a normal pace. For example, to spell ‘Smith, don’t say S as in Sam, M as in Michael, just say S M I T H.…try it again. Please spell your last name for me now.

50387

Retry 1

default_name_spelllast_collection_reprompts1

< default global > Saying just the letters of the alphabet, please spell your last name. For example, if your name were O’Connor, you would say O C O N N O R. Please spell the last name now.

50388

Retry 2

default_name_spelllast_collection_reprompts2

< default global > If your last name has an apostrophe, space or a hyphen in it, you can just skip that. For example, if you have a two part name like Folsom-Jones, you should drop the hyphen and not worry about capital letters. Just say f-o-l-s-o-m-j-o-n-e-s. Try spelling the last name one more time.

50389

Help

default_name_spelllast_collection_helpprompts1

I need you to spell just your last name. If your last name has an apostrophe, space or a hyphen in it, you can just skip that. It works best if you use ONLY letters and speak at a normal pace. For example, to spell ‘Smith, you don’t need to say S as in Sam, M as in Michael, just say S M I T H …try it again. Please spell your last name for me now.


Option

Vocabulary

DTMF

Confirm.

<LastName>

<alpha input>

N/A

Always


Confirmation Prompts

Message Number

Option

Name

Wording

Result

50392

Confirm

default_name_confirmation_initialprompt_part1

Okay. I think I’ve got it right now.


Okay. I think I’ve got it right now. Last name spelled <…>, Did I get that right?

50340

default_name_lastnamespelled

Last name spelled:

50342

default_confirmation_initialprompt_part2

Did I get that right?

00118

command

default_confirmation_initialprompt_part1


I think you said…


I think you said <…> Did I get that right?

50342

default_confirmation_initialprompt_part2

Did I get that right?


Option

Vocabulary

DTMF

Action

Confirm.

Yes”

Yes [it is]”

[Yes] that’s right”

Right”

[That’s] correct”

1

If “names_to collect” = LAST_FIRST

Go to: 1070_RespellFirst

Never

ELSE Go to: 4000_ExitSuccessPrompts

No”

No [it isn’t]”

[No] that’s not right”

2

Re-enter the dialog module per default behavior

Never

MaxFailure



Go to:3000_ExitFailurePrompt



Module Settings

Note: Confidence Level should be set to .72

Developer notes

Set Confidential Flag to TRUE

Set confidence levels to .400

3000_ExitFailurePrompt

Play Prompt

Apologize on exit

Entering from

1000_SayLastName, 1010_SpellLastName,1020_SayFirstName, 1030_SpellFirstName, 1040_ConfirmName, 1060_GetMistake, 1070_RespellFirst,1090_RespellLast,


Prompts

Message Number

Name

Wording

50393

default_name_exitfailureprompt

I’m sorry I’m having so much trouble with your name.


Condition

Action


Go to:BR3100_AfterHours_Check

NeedAssistanceWith = MaxNameRecognitionFailures


Module Settings

No barge-in

Note: This is the parameter exitfailureprompt and can be configured by setting this parameter.

4000_ExitSuccessPrompts

Play Prompt

Get the user’s first name.


Entering from

1040_ConfirmName, 1070_RespellFirst, 1090_RespellLast


Prompts

Message Number

Condition

Name

Wording

00120

If nomatchcount =1

default_successprompts1

Alright.

50294

If nomatchcount =2

Or

confirming Alt Name

default_successprompts2

Got it.

50295

If nomatchcount =3

default_successprompts3

Thanks for being patient.


Condition

Action

Always

Go to: BR5500_Alt_Name_Collected


Module Settings

No barge-in

Note: This is the exitsuccessprompts parameter and can be configured by setting this parameter.

BR5500_Alt_Name_Collected

Branch on Condition

<<In this cell, write your explanation of this Branch on Condition>>


Entering from

400- Name Check Condition, 4000_ExitSuccessPrompts


Condition

Action

IF AltNameCollected = True

Go to: PP6000_Ready_To_Submit

Else

Go to: DM9000_Check_For_Alt_Name


Event logging

V-MEDI-OtherLastName_1-(duration), T-MEDI-0000-(duration)

PP6000_Ready_To_Submit

Play Prompt

Tell caller we’re ready to submit information


Entering from

BR5500_Alt_Name_Collected, 1000_SayLastName


Prompts

Message Number


Name

Wording

10052

From 4000_ExitSuccessPrompts

60001

I’ve got everything we need. Hold on while I send off your request.

10053

From DM9000 or BR 1900

60002

Alright. I’ve got everything we need. Hold on while I send off your request.



Condition

Action

Always

Go to: DB7000_SubmitRequest


Event logging



Developer notes

No barge-in

DB7000_SubmitRequest

Database Query

Send off callers info for the first time for validation


Entering from

PP6000_Ready_To_Submit



Condition

Action

Always

Go to: BR8000_DB_Request_Validate_1st


Event logging


BR8000_DB_Request_Validate_1st

Branch on Condition

Branch on the return values from DB Dip 1 (DB7000_SubmitRequest_1st)


Entering from

DB7000_SubmitRequest


Condition

Action

IF DB Returns OK

Go to: PP10000_Task_Complete

Else if DB returns Account Blocked

NeedAssistanceWith = AccountBlocked

Go to: BR3100_AfterHours_Check

IF DB Rejects

NeedAssistanceWith = ValidationFailure

Go to: BR3100_AfterHours_Check


Event logging


DM9000_Check_For_Alt_Name

YesNo

Check to see if Caller might be listed under an alternate name


Entering from

BR8000_DB_Request_Validate_1st


Prompts

Message Number

Type

Name

Wording

Barge-in

10054

Initial

900010

Some people use another last name, such as a professional or maiden name, that might be listed under this social security number.

No

10092

Initial2


Do you have another last name? Yes or No.

Yes

10055

Retry 1

900020

< default global.> Would you like me to also check under another last name? Please say “YES” or “NO”.

Yes

10056

Retry 2

900030

< default global > If you think you might be listed under another last name, press one. Otherwise, press two.

Yes

10057

Timeout 1

900040

I’m sorry, but I didn’t hear anything. Would you like me to also check under another last name? Please say “YES” or “NO”.

Yes

55003

Timeout 2

900050

My apologies, but I still didn’t hear if you said anything. Please say “YES” if you think you might be listed under another last name, otherwise, say “NO”.

Yes

10058

Help

900060

Before I send off your request, I need to know if you might be listed under an alternate last name. For example you may also have a professional name, or maiden name or one from a previous marriage. Please tell me if you’d like me to include another last name with this request. Please say “YES” or “NO”.

Yes



Option

Vocabulary

DTMF

Action

Confirm.

Yes

Yes [please]”

[Yes] I do”

[Yes] I would”

Yeah”

1

Go to: 1000_SayLastName

NOTE: names_to_collect = LAST; AltNameCollected = True

Never

No

No [thanks]”

[No] I don’t”

[No] I do not”

[No] I wouldn’t”

[No] I would not”

2

Go to: PP6000_Ready_To_Submit

AltNameCollected = True

Never


DialogModule parameters

Parameter

Value

after_end_of_speech_timeout

500 ms

before_begin_of_speech_timeout

7,000 ms

allowing_barge_in

TRUE (For message 10054 = FALSE) <- Note change from usual setting.


Event logging



Developer notes

Set Confidential Flag to TRUE

PP10000_Task_Complete

Play Prompt

Acknowledge Task Completion


Entering from

BR8000_DB_Request_Validate_1st


Prompts

Message Number

Condition

Name

Wording

10089

Task = BEVE

100001

Okay. You’re all set. You should receive your Benefits Verification Letter in the mail within two weeks.

10090

Task = MRC

100002

Okay. You’re all set. You should receive your Medicare Replacement Card in the mail within four weeks. If you live in Puerto Rico, please allow eight weeks for delivery.


Condition

Action

Always

Go to: DM14000_Post_Options


Event logging



Developer notes

No barge-in

DM11000_ReturnToMain_or_HangUP

CustomContext

Caller needs assistance with something, but operators are not available. Ask if the caller wants to return to the main menu or hang up.


Entering from

BR3100_AfterHours_Check


Prompts

Message Number

Type

Condition

Name

Wording

10059

Initial

NeedAssistanceWith = SysUnavailable

1100011

I’m sorry; but the system is currently unavailable. I’m afraid you’ll have to try your call again later or try during business hours if you’d prefer to speak with an agent. But, if there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10061

NeedAssistanceWith = BadAOR

1100012

I’m sorry, but I can’t be sure if your new address is in the system yet. I’m afraid you’ll need to speak with an agent to complete your request. Please call again during business hours. If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10062

NeedAssistanceWith = ValidationFailure

1100013

I’m sorry, but I couldn’t process your request. I’m afraid you’ll have to call back and speak with an agent during business hours. In the meantime, if there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10063

NeedAssistanceWith = MaxNameRecognitionFailures

1100014


Unfortunately there are no agents available at this time. I’m afraid you’ll have to call back during business hours. But, if there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10064

NeedAssistanceWith = MaxTimeout

1100015

<default> To speak with an agent, please call back during business hours. If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10065

NeedAssistanceWith = MaxRetry

1100016

<default> To speak with an agent I'm afraid you'll have to call back during business hours.  If there's anything else you'd like to do, say main menu.  Otherwise you can say goodbye, or just hang up

10066

NeedAssistanceWith = UserRequestedAgent

1100017

Unfortunately, our offices are closed. To speak with an agent, please call back during business hours. If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10067

NeedAssistanceWith = MaxHelp

1100019

You know what? You might want to go through this with one of our agents. I’d suggest you try your call during business hours. If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10068

NeedAssistanceWith = AccountBlocked

1100021

Our records show that you requested that your account be blocked from access by this automated system, as well as by the Internet, even with a password, so you’ll need an agent to complete this transaction. If you want to unblock your account, the agent must handle that as well. Unfortunately, our offices are closed so you’ll have to call back and speak with an agent during business hours. In the mean time, if there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10069

Retry 1

1100020

< default global > I’m afraid you’ll have to call back and speak with an agent during business hours. In the mean time, if there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10071

Retry 2

1100030

< default global > Unfortunately, there are no agents available at this time. I’m afraid you’ll have to call back during business hours. But if there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang up.

10072

Timeout 1

1100040

Sorry, I didn’t hear you and I’m afraid our offices are currently closed. To speak with an agent, you’ll have to call back. If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10073

Timeout 2

1100050

Sorry, I still didn’t hear you and I’m afraid our offices are currently closed. To speak with an agent, you’ll have to call back. If you’d like to return to the main menu, say “MAIN MENU”. If you’d like to end your call you can say “GOODBYE” or simply hang up.

10074

Help

1100060

At this point, I’m afraid our offices are closed, so you’ll have to call back if you’d like to speak with an agent. But you do have two other options. You can either say “MAIN MENU”, or you can end the call by saying “GOODBYE” or simply hanging up.


Option

Vocabulary

DTMF

Action

Confirm.

MainMenu

Main Menu”

1

Go to: PP12000_Thanks_Before_Return

If necessary

Goodbye

Goodbye”

2

Go to: PP13000_Goodbye

If necessary


Confirmation prompts

Message Number

Option

Name

Wording

10075

MainMenu

1100080

You said you wanted to return to the ‘Main Menu’, is that right?


10076

Goodbye

1100081

You want to end this call; Is that right?


Confirmation Options

Vocabulary

DTMF

Confirm.

Yes”

Yes [it is]”

[Yes] that’s right”

Right”

[That’s] correct”

1

Never

No”

No [it isn’t]”

[No] that’s not right”

2

Never


DialogModule parameters

Parameter

Value

after_end_of_speech_timeout

1,000 ms

before_begin_of_speech_timeout

7,000 ms

allowing_barge_in

True


Event logging



Developer notes

On DM11000 MaxTimeout, Max Retry or MaxHelp Go to: PP13000_Goodbye

Disable Global Agent Command

PP12000_Thanks_Before_Return

Play Prompt


Thank caller before returning them to the main menu (N8NN).




Entering from


DM11000_ReturnToMain_or_HangUP




Prompts


Message Number

Condition

Name

Wording


10077

FOAP flag = 0

120001

Sure. I’ll transfer you now. [Closing Audio Icon]


00250

else

120002

250 milliseconds silence.





Condition

Action


Always

Go to: N8NN Main Menu 1100-Main-DM




Event logging






Developer notes


No barge-in


PP13000_Goodbye

Play Prompt

Say goodbye to the caller.


Entering from

DM11000_ReturnToMain_or_HangUP


Prompts

Message Number

Name

Wording

10078

130001

OK. Goodbye. [Closing Audio Icon]


Condition

Action

Always

Go to: [HANG UP]


Event logging



Developer notes

No barge-in

DM14000_Post_Options

CustomContext

Ask if the caller wants to return to the main menu or hang up.


Entering from

PP10000_Task_Complete


Prompts

Message Number

Type

Name

Wording

10079

Initial

1400010

If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10081

Retry 1

1400020

< default global.> If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10082

Retry 2

1400030

< default global > If you’d like to return to the main menu, say “MAIN MENU”. If you’d like to end your call you can say “GOODBYE” or simply hang up.

10083

Timeout 1

1400040

Sorry, I didn’t hear you. If there’s anything else you’d like to do, say “MAIN MENU”. Otherwise you can say “GOODBYE” or just hang-up.

10084

Timeout 2

1400050

Sorry, I still didn’t hear you. If you’d like to return to the main menu, say “MAIN MENU”. If you’d like to end your call you can say “GOODBYE” or simply hang up.

10085

Help

1400060

At this point, you have two options. You can either return to the main menu by asking for the “MAIN MENU”, or you can end your call by saying “GOODBYE” or hanging up.


Option

Vocabulary

DTMF

Action

Confirm.

MainMenu

Main Menu”

1

Go to: PP12000_Thanks_Before_Return

If necessary

Goodbye

Goodbye”,

2

Go to: PP13000_Goodbye

If necessary


Confirmation prompts

Message Number

Option

Name

Wording

10086

MainMenu

1400080

You said you wanted to return to the ‘Main Menu’, is that right?

10087

Goodbye

1400081

You want to end this call; Is that right?

Confirmation Options

Vocabulary

DTMF

Confirm.

Yes”

Yes [it is]”

[Yes] that’s right”

Right”

[That’s] correct”

1

Never

No”

No [it isn’t]”

[No] that’s not right”

2

Never


DialogModule parameters

Parameter

Value

after_end_of_speech_timeout

1,000 ms

before_begin_of_speech_timeout

7,000 ms

allowing_barge_in

True


Event logging



Developer notes

On DM14000 MaxTimeout, Max Retry or MaxHelp Go to: PP13000_Goodbye

Disable Global Command Grammar







[End of Specification]

File Typeapplication/msword
File TitleSSA BEVE/MRC UI Design Specification
AuthorRobby Kilgore
Last Modified ByTerri Banack
File Modified2012-04-19
File Created2012-04-19

© 2024 OMB.report | Privacy Policy
